Atomos Ninja V+ | 5-inch 8Kp30 4Kp120 1000 nit HDR HDMI Monitor-Recorder

The Ninja V+ is the next stage in the evolution of the multi-award winning Atomos Ninja, delivering up to 8Kp30 and 4Kp120 continuous recording in Apple ProRes RAW while inheriting HDR, 4Kp60 RAW and video as well as HDp120 slow motion from its little brother, Ninja V.

With the ability to capture in 8Kp30 and 4Kp120, the Ninja V+ allows you to stay ahead of the game and ensure that you have the flexibility to grow your system as projects demand. Future-proofed quality and formats allow you to stay compatible with newly released and existing cameras, in a world where new cameras are released frequently, and technology is advancing at an incredible pace.

The Ninja V+ takes advantage of the new Atomos Silicon Atom IC3, AtomOS 10 and the incredible efficiency of ProRes RAW to deliver these increased resolutions and frame rates. The new formats also integrate seamlessly into the timeline of your existing ProRes RAW or ProRes projects, without huge storage or processing overheads.

Ready For The Future

The Ninja V+ and Canon R5 deliver a compact and configurable 8K RAW and HDR camera system that is very affordable when compared with other 8K setups. The possibilities you have when shooting in 8K are a true game-changer, as Canon and Atomos have just democratized 8K for the masses with no compromise in quality.

More Power. Less Weight.

Pairing the Ninja V+ with the Canon R5 gives you a powerful yet compact 8K camera package that fits in your hands and can be flexibly built out to suit your needs. It can become the basis of a compact cinema rig or be flown on gimbals and stabilizers. It’s also easy to create an incredibly lightweight setup, as the Canon R5 with a 24mm Cine lens, Ninja V+, NPF battery and media comes in under 3KG/7lb, which can be easily carried by a wide range of aerial drones, as well as vehicles and robot arms.

Extra Resolution Gives You Creative Flexibility

With the broad canvas of 8K resolution, your options for creative crops into a region of interest allow you to extract multiple 4K shots from a single camera angle. This allows you to create additional shots for cutaways to break up the edit, which are much higher resolution than if the shots were extracted from a single 4K source.

Stabilize Without Compromise

The incredible resolution of 8K video means that even after cropping into the image as part of the stabilization process, the final shot will likely still have a resolution of 4K or even 6K. This means that it can integrate with your other 8K footage on the timeline, and still look great.

Razor Sharp Screenshots

High-resolution screenshots from 8K full-frame cameras also offer the ability to create scene plates for small scale virtual production stages or use them in other content platforms.

See The Unseen

The Ninja V+ allows you to capture content at up to 4Kp120 in pristine ProRes RAW for high frame rate video that has exceptional image quality. This is a great alternative to using the internal compressed codecs on your camera for high frame rate recording, as they can apply higher levels of colour compression and subsampling, leading to potential artefacts or limitation in the edit/grade.

Z CAM E2 / E2-M4 Series Cameras

Capture and visualize the unseen with 4Kp120 recording at up to ProRes RAW from the Ninja V+ Z CAM E2 /E2-M4 models, with more models to follow. Fully harness the dynamic range of the sensor, capture every aspect of motion and movement directly via RAW over HDMI. Add to this the benefit of being able to playback the high frame rate video captured on the Ninja V+ at various playback speeds to preview the adjustments you can make on your NLE timeline.

An Incredible Codec Arsenal

With the flexibility of providing options for RAW, visually lossless edit-ready files, and proxy/sharable files, you have the ability to scale your needs for quality, and file size.

• ProRes RAW – supporting 16bit RAW outputs from camera via HDMI and optionally via SDI
• ProRes - An industry-standard edit-ready codec from Apple with scalable levels of compression.
• Avid DNx - An industry-standard edit-ready codec for Avideditors with scalable levels of compression.
• H.265 (HEVC) - The highly efficient compressed codec allows you to create high-quality files with a low bit rate and small file size for sharing. You can also create 4K HDR 10-bit deliverables and have the option to ‘bake in’ LUTs to achieve the final pixel LOOK without the need to grade the footage.

AtomX Modules

AtomX SDI

Upgrade your Connection options
The AtomX SDI Expansion Module locks into place via the modular expansion slot and adds the quality and convenience of SDI connectivity to your Ninja V+, which allows you to monitor and record SDI video up to 4Kp60 from a range of professional cameras and video sources.

HDMI / SDI

Cross Conversion
When an AtomX SDI Expansion module is attached to your Ninja V+, you can cross convert HDMI and SDI signals. This means that where you have an HDMI source connected to your Ninja V+, you can output an SDI signal from your AtomX SDI Expansion module.

AtomX SYNC

Making multi-camera mainstream
The AtomX SYNC module brings wireless timecode, sync and control technology to the Ninja V+, and you can connect multiple AtomX SYNC enabled Ninja V+ units to create a Timecode Systems powered multi-camera sync network. Remotely trigger frame-accurate record start/ stop recording, monitor, battery and disk capacity information from the SYNC server configured Ninja V+.
The SYNC module provides continuous power to keep your Ninja V running while you change the main battery or DC input.

AtomOS 10.92.00

• Panasonic S5II RAW Support
• Panasonic S5IIX RAW Support
• Fujifilm X-S20 RAW Support
• Support of additional Anamorphic De-Squeeze modes
• AirGlu2 Improvements

AtomOS 10.90.00

New Features

• Support for the newly introduced Atomos Cloud Studio Subscription Tiers
• Support for Atomos Live Production (Fully featured BETA)
• Changes to Frame.io C2C Implementation
• Changes to RTMP Streaming Implementation
• Support for NDI HX2 TX
• Canon R6 MKII ProRes RAW Support
• Fujifilm X-T5 ProRes RAW Support

AtomOS 10.84.00

• AtomRemote App Support for ATOMOS CONNECT
• Introduction of an additional H.265 compression option
• General stability & performance improvements for H.265 recording and live-streaming

For more information on the new features, improvements and known limitations, refer to the release notes for AtomOS 10.84.00.

AtomOS 10.83.00

Features:

• Sony ILME-FX30 RAW Support
• Sony ILME-FR7 RAW Support

AtomOS 10.82.00

New Features

CONNECT to ATOMOS Cloud Studio

Pair your Ninja V and get ready to access a powerful collection of new cloud-based video production services

1. Dial-in your local date, time & time zone in the Date menu on your Ninja V.
2. Put your Ninja V into CONNECT mode via the button in the CONNECT menu
3. Connect your Ninja V to the Internet via Wi-Fi or Ethernet
4. Create a new account on cloud.atomos.com or log into your existing ATOMOS Cloud Studio account
5. Add a new device to your account and select Ninja V.
6. Enter the three words that are displayed in the Ninja's CONNECT menu after pressing the “Pair” button.

Note: If you've previously added your Ninja V to your account for Streaming, you don't need to add or re-pair it again.

Go live via ATOMOS Stream

You can now stream to Facebook Live and Custom RTMP Destinations

• Select and configure the streaming output destination via atomos.cloud
• Note: Destinations can be set as: Twitch, YouTube, Facebook and Custom RTMP
• Once configured, the Ninja V receives the streaming destination parameters from the Atomos Cloud, and you can start & stop the streaming output by pressing the LIVE button.
• Supported YCC video Input Resolutions: 3840 x 2160, 1920 x 1080
• Note: Resolutions above 1080p will be downsampled to 1920 x 1080 Pixels
• Supported Input Frame Rates: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 60p

Note: Due to the large number of streaming and social media platforms that accept custom RTMP sources for live streaming, it is not possible to test every available option. Please take a look at our FAQ article that lists the platforms that have been tested so far, and don't hesitate to reach out to our support team if a streaming platform you'd like to use isn't available. https://atomos.zendesk.com/hc/en-us/sections/205529868-Setup-connectivity

Note: Currently, this device only supports streaming to sites that don't require authentication unless they accept it as part of the URL.

Bug Fixes and Improvements

• Improvements to accuracy of WiFi connection status, including status shown in the WiFi menu tab and the changing status of the WiFi icon in the top info bar.
• The device's MAC address is now displayed in both WiFi and Ethernet tabs.
• The WiFi On/Off status is saved on reboot.
• Users are presented with a dialogue window to confirm if they want to start or stop streaming.
• Tapping the C2C Status Icon allows file upload status to be hidden or shown.
• In Playback mode, a shortcut to the Proxy folder was added to check the upload status of all clips.
• Capture to Cloud – Upload Icon States
• If files have been recovered, Proxy files will not be uploaded and highlighted with a red exclamation mark icon. The recovered files must be manually uploaded to the Cloud.
• The yellow icon indicates that the clip has not yet been uploaded but is in the upload queue.
• The green tick icon indicates that a clip has been successfully uploaded.
• The record tally light on the CONNECT accessory can now be enabled or disabled through the Ninjas menus.

Known Limitations to be resolved in future releases:

• It may take up to 10 seconds for Wi-Fi and Ethernet connections to re-established when users switch between record and playback mode. Please allow the system time to automatically reconnect to your network.
• Enabling Wi-Fi may be intermittent. A dialogue message may suggest a system reboot to fix.
• Live Streaming is only available when using standard YCC 422 video inputs, and when the record codec is set to either ProRes or DNx. If ProRes RAW or H.265 are selected as the record codec, streaming isn't available.
• There may be some faint background noise when recording 1080p23.98/24 in ProRes or DNx.
• If the user boots into ProRes RAW recording mode with a YCC SDI Input, the monitoring image may be incorrect. Monitoring and Recording whilst outputting a RAW signal to the Ninja V in ProRes RAW mode will work as expected.
• Network Record Control is not available when H.265 is selected as the record format when using the AtomX SYNC Module or Atomos CONNECT accessory.
• If switching between different camera models whilst HDMI Compatibility mode is selected, ensure that you reboot the Ninja V before connecting a new camera.

AtomOS 10.81.00

Features:

• Support for FRAME.IO – CAMERA TO CLOUD (C2C)*

* Requires ATOMOS CONNECT

AtomOS 10.76

Features:

• OM-1 ProRes RAW Support

AtomOS 10.75

• Leica SL2-S HDMI RAW Support

AtomOS 10.73

Features

• Custom Frame Guides
  Setup custom frame guide overlays to preview how images will look when cropped to meet specific or unique requirements.
• Frame Grab
  Capture and save reference stills during playback and recording with a tap of the new Frame Grab button.
• Onion Skin Overlay
  Load a frame grab or preexisting picture, then select from three levels of opacity or activate a split screen view to compare or match the still with the live image.

Each feature provides a fresh way to use the NINJA V/V+ to perfect each shot or explore new ways to make films. When you get your hands on one of these devices, the biggest challenge will be deciding which of the options you’ll explore first.

AtomOS 10.73

New Features:

Canon EOS R5 C HDMI RAW Support

• ProRes RAW Recording:
• 6K (5952 x 3140) at 23.98p, 24p, 25p, 29.97p
• 3K (2976 x 1570) at 23.98p, 24p, 25p, 29.97p, 50p, 59.94p
• WB and ISO Controls for FCP Settings slider adjustments

AtomOS 10.72.1

Updating to AtomOS 10.72.1

Features

• Sony FX6 HDMI RAW Support

For more information, please refer to the firmware release notes.

Firmware Update Procedure

Atomos recommends that your Ninja V is plugged into mains power before commencing the firmware update.

1. Insert a compatible, formatted HDD/SSD into the Docking Station.
2. Unzip the downloaded file and copy the ATOMNJV.FW file to the root of the HDD/SSD.
3. Eject the HDD/SSD (according to operating system guidelines).
4. Insert the HDD/SSD into the Ninja V
5. Power the Ninja V on and the firmware update process will begin automatically.
6. If your Ninja V is already powered on, you will be prompted to perform the firmware update when a drive containing new firmware is inserted.
7. Once the update is complete, your Ninja V will power itself off.
8. Power your Ninja V on and check the firmware version. (menu>info tab)

For further information and troubleshooting, click here.

AtomOS 10.71

Features

• 5.9K, 4.1K & 3.5K Anamorphic ProRes RAW recording from the Panasonic LUMIX BS1H
• 5K p30 ProRes RAW recording from Canon EOS R5
• Enhanced functionality for AtomX CAST

AtomX CAST Features

When using AtomX CAST with Ninja V, the following features are now supported:

• Introduction of “Dip to”-transitions, available in black & white. These can be automatically applied on each switch from one input to another.
• Addition of updated program recording options. Choose “Clean” to record a clean feed of the currently switched to input or use the new “CAST Program” mode. In CAST Program mode, graphical overlays and the picture in picture (PiP) get recorded onto the SSD/HDD inserted in the Ninja V. The recording contains the new “Dip to”-transitions as well as the Fade In/Fade Out buttons used to fade in or fade out of your program during recording.
• Interlaced signals are now supported. An automatic pulldown conversion gets applied to them, which then gets conformed to the Project Rate.
• Audio delay options are now available, which apply frame delays to all audio inputs including analog and embedded audio (calibrate feature not supported).
• General bug fixes.

  ---

  AtomOS 10.7.1

  Updating to AtomOS 10.7.1

  Note:

  This release is primarily focused on providing support for the AtomX CAST switching dock. Please consult the Quick Start Guide (QSG) included in the box with the AtomX CAST for details on how to connect the device. Do not install this firmware if you plan to record RAW from an EOS R5 with your Ninja V. For this, please install the AtomOS 10.68 Public Beta.

  ---

  AtomOS 10.64

  Updating to AtomOS 10.64:

  Additional support for Sony Alpha 7SIII

  • RAW Recording: WB and ISO metadata support for FCP settings slider adjustments

  Firmware Update Procedure:

  Atomos recommends your Ninja V is plugged into mains power before commencing firmware update.

  ---

Download the latest Firmware and Software

• Spec Sheet
• Stills to movie: a pro’s story - Photography News
• Ninja Comparison
• Atomos Brochure 2023
• Canon EOX R5 C Accessories Brochure
• Download HiRes Images

• Ninja V+ unit with H265 Pre-Activated
• EVA style hard case
• Neoprene Sleeve Case
• Master drive caddy
• Battery Eliminator
• 1x DC locking connector
