RRP: £1,699.00
Your Price: N/A
Mfr. Part #: ATOMSHGAV1
Our Part #: AOATOMSHGAV1
EAN #: 0814164023382
Description
Shogun AV-19 is a powerful 19 inch 4K HDR monitor-recorder-switcher designed for professional live production, broadcast, and video village environments. With 4 SDI inputs, ISO recording, live multi-camera switching, NDI HX3 over Ethernet, ProRes/DNx/ProRes RAW, XLR audio, and advanced monitoring tools, it delivers a complete Monitor-Record-Switch workflow for modern studio and outside broadcast environments.
Its rugged, rack-mountable design and crisp DCI-P3 display make it an ideal central hub for multi-camera monitoring, with built-in switching that supports four ISO feeds plus a fifth program channel for smooth, real-time operation.
Shogun AV-19 includes the monitoring tools professionals expect - EL Zone™, waveform, vectorscope, focus peaking, and full LUT support, and records Apple ProRes, ProRes RAW, and Avid DNx up to 10-bit 4:2:2 from SDI or HDMI. It offers flexible media options via CFexpress or USB-C, and integrated camera control provides direct access to key exposure settings on supported mirrorless systems.
With native NDI HX3 and built-in Ethernet, Shogun AV-19 delivers high-quality, low-latency IP video over a single RJ45 cable, making it ideal for those transitioning to IP-based production.
Professional calibration support and a fully integrated audio system - including balanced XLR I/O with 48V phantom power, embedded SDI/HDMI audio, speakers, and headphone monitoring - round out a complete, ready-to-deploy solution for broadcast and event environments.
Use cases:
• On-set monitoring
• Confidently manage complex productions with a large, colour-accurate 4K HDR display that’s ideal for directors, technical directors, and camera operators
• Technical & confidence monitoring
• Bright, 19-inch 4K HDR display with comprehensive technical monitoring tools including EL Zone™ false colour, focus peaking, waveform & more
• Live switching & routing
• Live switcher capable of playing and recording up to four ISO camera feeds, for broadcasts and live events
Features:
• 19-inch, 4K HDR DCI-P3 7RU rack-mounted monitor
• Record in ProRes, ProRes RAW, Avid DNx to CFexpress or external USB-C storage
• Record up to four isolated camera feeds (ISOs), plus a fifth program output
• Live multi-camera monitoring
• 2 x 12G-SDI + 2 x 3G-SDI in, 12G-SDI out, HDMI in/out with XLR audio
• Comprehensive technical monitoring tools including EL Zone™ false colour, focus peaking, waveform & more
• Transmit and receive NDI® HX3 over Ethernet
• User-definable function buttons
• Log to LUT viewing, supporting 3D & .cube
• Backup recording for redundancy
Shogun AV-19 is a powerful 19 inch 4K HDR monitor-recorder-switcher designed for professional live production, broadcast, and video village environments. With 4 SDI inputs, ISO recording, live multi-camera switching, NDI HX3 over Ethernet, ProRes/DNx/ProRes RAW, XLR audio, and advanced monitoring tools, it delivers a complete Monitor-Record-Switch workflow for modern studio and outside broadcast environments.
Its rugged, rack-mountable design and crisp DCI-P3 display make it an ideal central hub for multi-camera monitoring, with built-in switching that supports four ISO feeds plus a fifth program channel for smooth, real-time operation.
Shogun AV-19 includes the monitoring tools professionals expect - EL Zone™, waveform, vectorscope, focus peaking, and full LUT support, and records Apple ProRes, ProRes RAW, and Avid DNx up to 10-bit 4:2:2 from SDI or HDMI. It offers flexible media options via CFexpress or USB-C, and integrated camera control provides direct access to key exposure settings on supported mirrorless systems.
With native NDI HX3 and built-in Ethernet, Shogun AV-19 delivers high-quality, low-latency IP video over a single RJ45 cable, making it ideal for those transitioning to IP-based production.
Professional calibration support and a fully integrated audio system - including balanced XLR I/O with 48V phantom power, embedded SDI/HDMI audio, speakers, and headphone monitoring - round out a complete, ready-to-deploy solution for broadcast and event environments.
Use cases:
• On-set monitoring
• Confidently manage complex productions with a large, colour-accurate 4K HDR display that’s ideal for directors, technical directors, and camera operators
• Technical & confidence monitoring
• Bright, 19-inch 4K HDR display with comprehensive technical monitoring tools including EL Zone™ false colour, focus peaking, waveform & more
• Live switching & routing
• Live switcher capable of playing and recording up to four ISO camera feeds, for broadcasts and live events
Features:
• 19-inch, 4K HDR DCI-P3 7RU rack-mounted monitor
• Record in ProRes, ProRes RAW, Avid DNx to CFexpress or external USB-C storage
• Record up to four isolated camera feeds (ISOs), plus a fifth program output
• Live multi-camera monitoring
• 2 x 12G-SDI + 2 x 3G-SDI in, 12G-SDI out, HDMI in/out with XLR audio
• Comprehensive technical monitoring tools including EL Zone™ false colour, focus peaking, waveform & more
• Transmit and receive NDI® HX3 over Ethernet
• User-definable function buttons
• Log to LUT viewing, supporting 3D & .cube
• Backup recording for redundancy
EAN # : 0814164023382
