CineView M7H Pro series All-in-One Wireless Smart Monitoring Ecosystem

Master Color Accuracy
Stunning, color-accurate professional 7-inch monitors crafted for professional uses.

Unrivaled display precision
Each unit is factory-calibrated to achieve near-perfect color accuracy.

Edge-Lit Backlight System, for Precise Bright & Dark Control
Achieving high brightness is easy, but maintaining accurate colors is challenging. CineView M7 series features a 1000:1 ultra-high contrast ratio combined with a fully laminated high-transmittance display, effortlessly handling both dark and bright scenes. Built with Edge-Lit backlight system with intelligent brightness control enables pixel-level precision, delivering true-to-life color reproduction without distortion.

High Bright Fully Laminated Display - True Colors Under Direct Sunlight
CineView M7 series is equipped with high transparency screen, enhanced by exclusive DXC coating, increasing light transmittance to99%while significantly reducing reflectivity. Even in bright outdoor environments, the screen maintains exceptional clarity and color accuracy.

All in One Wireless Workstation
CineView M7 Series features integrated long-range wireless video transmitter and receiver capabilities, seamlessly connecting to any Accsoon CineView transmitter. It leverages Accsoon’s patented Dual-Band transmission technology for ultra-low latency wireless monitoring. Nail every shot with cinematic grade tools like LUT box, false color and waveforms-all controlled through customizable buttons.

Compatibility with CineView TX/RX system*up to Dcl 4K60 wireless monitoring
• In RX mode: can receive from CineView M7 Pro (TX) /M7H Pro (TX) or Master 4K / HE / SE / 2SDl.
• In TX mode: can transmit to CineView M7 Pro (RX) /M7H Pro (Rx) / Master 4K, mobile devices.

Simultaneously and bi-directional record on the camera, as well as the monitor.

AF touch focus works in any zone, just tap to shift focus or drag the box to follow your subject.

The main parameter control menu brings up shutter speed, aperture, sensitivity (ISO) and white balance options in the top status bar of the monitor.

One Step Ahead Redefining Smart Monitoring
CineView M7 Series powered by 8K high-performance processors and a smart operating system is designed to adapt to the evolving needs of modern production.

On-set Monitoring, Reimagined
CineView M7 Series delivers cinematic standard calibrated color with 127-point 3D LUT precision. Its LUT Box function enables multi-screen color consistency via SDI/HDMI outputs, revolutionizing on-set color workflow.

Format Conversion Flexibility
Engineered with ground breaking architecture, CineView M7 Series delivers high processing ability to handle 961+ video format combinations effortlessly - from 4K60 to 1080P, even different frame rate outputs.

Features:
• Display screen 7" LCD
• Ultra high resolution capacitive touchscreen
• Resolution1920 × 1080 pixels
• Brightness 1000 nits
• Contrast ratio 1000:1
• Viewing angle 176°/176°
• Backlight type Edge-Lit Ultra-transparent LED Backlight
• Screen color calibration Supported
• LUT 1D and 3D Cube LUTs Supported
• 1D: up to 4096 points
• 3D: up to 127 points
• Video input port HDMI® 2.0
• Video output port HDMI® 2.0
• DC port 6.0~16.8V 5.5mm×2.1mm Center Positive
• Compatible battery Compatible with NP-F550, NP-F750, NP-F970 Batteries
• USB-C power input port PD3.0 9V/3A, 12V/3A, 15V/3A
• USB-C power output port Maximum: 5V/2A
• Microphone jack 3.5mm TRS
• Headphone jack 3.5mm CTIA
• Microphone input audio sampling 16bit, 48KHz
• Power consumption 12W–28W (Varies according to actual usage)
• Housing Aircraft-grade Aluminium Alloy
• Heat dissipation Active + Passive Cooling
• Wireless transmission latency 60ms
• Wireless transmission distance Dual-Band Connection: 350 meters
• Work environment temperature –10°C – 40°C
• Weight (antennas excluded) 494.3g
• Dimensions (antennas excluded) 182.2×120.7×31.5mm

EAN # : 0607609770572
