Networking Adapters

Presto 10G Base-T Ethernet 2 Port PCIe Card

Sonnet

Presto 10G Base-T Ethernet 2 Port PCIe Card

Presto 10GbE 10GBase-T Dual-Port 10 Gigabit Ethernet PCI Express 3.0 Card

Product Code: SON-G10E2XE3

Suggested Retail Price £285+VAT

Where to buy

Stock status: In Stock; available from resellers

Kit List

View your Kit List
  • Adds 10GbE Connectivity to Mac Pro Towers, Windows PCs, and Linux Servers - Powerfully simple way to add high-performance 10GbE connectivity to your computer with PCIe slots
  • Optimized for Thunderbolt™ - Ideal for use in Sonnet's Echo™ Express and xMac™ Thunderbolt-to-PCIe card expansion systems
  • Cost Effective - Connects to 10GbE infrastructure via inexpensive CAT-6 or CAT-6A cables at distances up to 55 or 100 meters, respectively
  • Simple Setup - Low-profile x4 PCI Express® 3.0 card installs into an available slot, and after a simple driver installation, configures through OS X Network control panel or Windows Device Manager
  • Supports Transparent Failover - Keeps your computer connected in case a single cable is disconnected or one of the ports fails
  • Supports Link Aggregation (Teaming) - Increases throughput beyond what a single connection can sustain

Computer Compatibility

  • Mac Pro (3,1 or 4,1 or 5,1), Xserve (3,1), PC desktop, or server with full-height or low-profile PCIe slots

OS Compatibility

  • OS X 10.8.5+
  • macOS High Sierra compatible
  • 64-bit editions of Windows 10, 8, 7; Server 2016, 2012, 2008
  • Linux

Thunderbolt Compatibility

  • Mac or PC via a Thunderbolt-to-PCIe Card Expansion System

Warranty

All new Sonnet Products purchased on or after January 1, 2019, have a Two Year Limited Warranty, except as listed here. All new Sonnet Products purchased on or before December 31, 2018, have a One Year Limited Warranty, except as listed here.

Technology Guides

Ultra-Fast 10 Gb/s Network Connection

With creative pros’ increasing demand for greater data transfer speeds and more bandwidth over shared networks, it’s no wonder that 10 Gigabit Ethernet (10GbE) use has skyrocketed—this high-speed cabled networking standard offers ten times the performance of Gigabit Ethernet, the common wired network connection included with most computers today. To get your computer up to speed, you’ll have to adapt—Sonnet’s Presto™ 10GbE 10GBASE-T PCIe 3.0 card is a powerfully simple and cost-effective way to add dual-port copper 10GbE connectivity to your Mac Pro® tower or Windows® PC, or Linux® server.

Simple Set-Up. High-Performance Computing.

The Presto 10GbE 10GBase-T card enables you to connect your computer to high-speed infrastructure and storage without stepping down in speed. Setup is simple—after installing the low-profile card into an available x4 or larger PCIe slot in your computer, just download and install a driver, connect to the switch or device’s 10GbE ports via inexpensive CAT-6 or CAT-6A copper cabling at distances up to 55 or 100 meters, respectively, and then configure the card through the OS X® Network control panel or Windows Device Manager. This Sonnet solution is perfect for high-performance computing where low latency, high bandwidth, and low CPU overhead are required.

Its increased throughput performance and low host-CPU utilization are achieved through functions such as flow control support, 64-bit address support for systems using more than 4GB of physical memory; and stateless offloads such as TCP, UDP and IPv4 checksum offloading, enabling your computer to perform better while large files transfers or high I/O operations take place. Wake-on-LAN support enables remotely waking your computer when you need it, and not wasting energy when you don’t. With its dual ports, this Sonnet adapter supports transparent failover to keep your computer connected in case a single cable is disconnected or one of the ports fails, and it also supports link aggregation for increased throughput.

Optimized for Thunderbolt

Got a Thunderbolt connection, but no PCIe slot? Presto 10GbE 10GBase-T is ideal for use in one of Sonnet's Echo Express or xMac Thunderbolt-to-PCIe card expansion systems—the combo enables you to add ultra-fast 10GbE network connections to any Mac® or Windows PC with a Thunderbolt 2 port.

Editing in the 21st Century: why you need 10GbE

Working on a local copy of a creative project may be your default. If your central storage and network can’t support the data rates you need for multiple streams of high resolution video, it may be your only option. That process of transferring files from shared storage to your desktop (and back again), is not only slow, it’s also extremely inefficient. To work at speed, you need the editor, FX artist, audio, colourist and titles to collaborate and work as a team.

Sonnet Technologies at BVE 2018

NEW: Thunderbolt™ 3 External Graphics (eGPU) SolutionsAt BVE 2018, Sonnet will showcase its new eGFX Breakaway™ Box 650, a Thunderbolt™ 3 to eGPU PCI Express® (PCIe®) card expansion system designed and qualified specifically for large, power-hungry video graphics processing unit (GPU) cards, including the AMD Radeon™ RX Vega 64 and overclocked NVIDIA® GeForce® GTX 10 series-based cards. The 650 model enables the use of all GPU cards that support connecting to a computer over Thunderbolt — such as AMD Radeon R9, RX, RX Vega, and Pro WX models and NVIDIA GeForce GTX 9 and 10 series, Titan X and Xp, and Quadro® models — with Thunderbolt 3-equipped computers, providing GPU support for computationally intensive applications and games. (Lists of supported computers and GPU cards are available at www.sonnettech.com/product/egfx-breakaway-box.html). Mac®- and Windows®-compatible, the new Sonnet system is the coolest and quietest eGFX box on the market, with a built-in, variable-speed, temperature-controlled fan that quietly and effectively cools the installed card.

Sonnet - macOS High Sierra Compatibility Information

Sonnet is currently testing product compatibility for macOS 10.13 (High Sierra). The following are compatible:

  • Presto 10GbE 10GBase-T Dual-Port 10 Gigabit Ethernet PCI Express 3.0 Card
  • Two mounting brackets
  • Documentation
