Hedbox NINA M | Mini V-Mount Battery 99.20 Wh 2x D-tap & USB-A and USB-C Out OLED Display with IDR System

Hedbox

NINA M

Mini V-Mount Battery 99.20 Wh 2x D-tap & USB-A and USB-C Out OLED Display with IDR System

Product Code: HEDNINAM

Suggested Retail Price £250+VAT

Where to buy Videos

Have a question about this product or want to request a demo?

Contact Our Technical Team

Kit List

View your Kit List
  • Mini V-Mount Battery 99.20 Wh 2x D-tap & USB-A and USB-C Out OLED Display with IDR System
  • Capacity Percentage Display
    Upon pressing the IDR button (Indication Display Ring)
    The OLED Display shows the battery capacity status in percentage (%)
  • Remaining Time Display
    Upon pressing the IDR button ( Indication Display Ring)
    The OLED Display shows the battery capacity remaining time in minutes
  • Total Usage Display
    Upon pressing the IDR button (Indication Display Ring)
    The OLED Display shows the total usage of the battery lifetime
    The usage is counted per circle (one circle is total charging/discharging)
  • USB Charging Display
    Upon pressing the IDR button ( Indication Display Ring)
    The OLED Display shows the charging process of the battery
    The charging readout is shown as an indication and a percentage
  • V–Mount Connection Holder
    NINA M has a standard V-Mount connection. The V-Wedge is made from a special structure of high-quality dur-aluminum. This material enables safe, rugged, and reliable mounting of the battery on all products on which the battery will be used
  • Battery Charging OLED Display
    During the Battery Charging process, via the USB Charger/cable, the battery OLED Display shows the real-time charging process. The readout is visibly shown in the charging indication progress and the current state of battery capacity status. The battery Capacity status is counted per one percent (1%)
  • Two D-Tap, Power Out - USB-A and USB-C
    Through its additional integration on both sides D-Tap DC Power output. The NINA M battery can deliver two times 16.8V, 135W/ 8A of power. An extra USB-A power provides 5V/3A , 9V/2A , 12V/2A and another USB-C can sustain 5V/3A、9V/3A、12V/3A、15V/3A、20V/3.25A (65W) Both USB outputs support PD3.0/QC2.0/QC3.0/PPS/AFC/FCP/SCP/DCP-1.5A/APPLE-2.4A This allows the charging of mobile phones, tablets, or other accessories using one single battery
  • Low Capacity Emergency ALARM
    When the battery capacity drops below 20%. The battery IDR emergency ALARM lights up. The strong and visible fleshing IDR ring, (silent mode no buzzer), warns the user that the battery has fallen below 20% capacity. This unique function gives the camera operator enough time to finish the recording and replace the battery in time
  • USB-C LED Cable Included
    The cable has an LED display that in real-time shows charging power, and charging status. Built-in smart chips monitor the charging power and adjust current and voltage automatically, avoiding damage to the battery in case of an unstable current. (Please note display module just shows charging power, it neither increases nor decreases charging current)
    • Cable Lenght: 1.2m / 3.93 ft
    • Cable Type: USB-C to USB-C
    • Power Delivery 3.0, Qualcomm Quick Charge 5.0 protocol (2.0/3.0/4+)
    • Super fast charging 2.0 and PPS 65W/45W/25W

The NINA series of Hedbox stands for High Performance and High Safety Design mini Battery Pack. The new and revolutionary IDR System provides full control and display of the battery status. On the high-contrast OLED Display, the Battery Capacity, Remaining Time, Circle usage, and Charging function are visible during the day and night.

Through its additional 2xD-Tap DC output the NINA can deliver power to all additional accessory devices. An extra USB-A and USB-C power input allows the charging of the battery with regular USB chargers. Also the same can be used as Power output for mobile phones, tablets, or other accessories using one single battery.

Hedbox FIREBAG-M
FIREBAG-M

Medium Size Li-Ion Battery Safe Bag
[HEDFIREBAGM]

SRP: £9+VAT
Hedbox RPC-D65W
RPC-D65W

USB-C LCD Cable
[HEDRPCD65W]

SRP: £9+VAT

Atomos

  • 1x NINA M BATTERY PACK
  • 1x USER MAUNAL (ENGLISH)
  • 1x 1 YEAR LIMITED MANUFACTURER'S WARRANTY
