Production Systems

Pearl Mini

Epiphan Video

Pearl Mini

Portable all in one video production system

Product Code: EPI-ESP1441

Suggested Retail Price £2,995+VAT

Where to buy Videos

Stock status: In Stock; available from resellers

Kit List

View your Kit List

Technology Guides


  • Portable all in one video production system
  • Record, stream and switch up to three full HD video inputs from HDMI, IP, SDI, and USB sources
  • Stream to viewers everywhere - Simultaneously live stream to YouTube, Facebook or other content delivery networks and content management systems using SRT, HLS, MPEG-DASH, custom RTMP/RTMPS, and RTSP
  • Locally share unicast or multicast streams to up to 50 viewers with popular streaming protocols such as HTTP, HLS, FLV, ASF, UPnP, and SAP
  • Stream content securely with Secure Reliable Transport (SRT) end-to-end 256 bit AES encryption, HLS and MPEG-DASH over HTTPS, as well as Real Time Messaging Protocol Secure (RTMPS)
  • 1080p HD Recording
  • Automatic or manual file uploads
  • Save recordings directly to a 512 GB EXT4 SD card  (sold separately)
  • Switch video sources live
  • Design custom layouts like PiP with the easy drag-and-drop custom layout editor

The most reliable, all-in-one video production system that’s small in size and big on pro features.

Record, stream and switch up to three full HD video inputs from HDMI™, SDI, and USB sources. Epiphan Pearl Mini™ takes your video production to the next level.

Stream to viewers everywhere

Simultaneously live stream to YouTube, Facebook or other content delivery networks and content management systems using SRT, HLS, MPEG-DASH, custom RTMP/RTMPS, and RTSP. At the same time, use the built-in streaming server to stream locally to web browsers, smart TVs, and set-top boxes. Integration with Kaltura and Panopto CMSs means no complicated stream URLs to set up. Just schedule your webcast event and start streaming.

Share your webcast

Locally share unicast or multicast streams to up to 50 viewers with popular streaming protocols such as HTTP, HLS, FLV, ASF, UPnP, and SAP.

Secure streaming

Stream content securely with Secure Reliable Transport (SRT) end-to-end 256 bit AES encryption, HLS and MPEG-DASH over HTTPS, as well as Real Time Messaging Protocol Secure (RTMPS).

Leverage SRT for high-quality, low-latency video streaming

The Secure Reliable Transport (SRT) protocol uses the latest in live streaming technology to keep your live video productions looking great. Add a remote guest or contributor over SRT to bring professional-quality sources into your Pearl-powered productions.

1080p HD Recording

Pearl Mini’s hardware-accelerated encoder provides flawless H.264 encoding for maximum performance. Record a program and ISO in AVI, MP4, MOV, or MPEG-TS formats directly to a 512 GB EXT4 SD card* and automatically upload to a USB stick or server on the network.

*User supplied

Automatic or manual file uploads

Fail proof recordings and upload files automatically to a server while you record locally to the SD card. Transfer recordings to a USB drive or network storage (FTP or SFTP) for post processing.

SD Card

Save recordings directly to a 512 GB EXT4 SD card (user supplied). Easily download recordings and manage files using the Admin panel or Epiphan Live.

Switch video sources live

Incredibly easy to use, Pearl Mini’s 7 inch touch screen makes switching between video sources and layouts a breeze. Or use the browser-based Epiphan Live and switch from almost anywhere using a tablet, PC, or mobile phone.

Custom layout designer

Design custom layouts like PiP with the easy drag-and-drop custom layout editor. Combine, crop, and scale video sources to make dynamic layouts. Add transparent png images, custom backgrounds, text overlays, timestamps and more.

Easy PiP layouts

Make PiP, side-by-side, three quarter layouts and more for dynamic looking visual presentations. The possibilities are endless.

Images and dynamic text

Customize the look of your event with transparent .png images and custom backgrounds. Easily add timestamps and other dynamic text content to layouts. Create custom system variables for even more flexibility, like adding the current GPS location.

Video inputs

Connect cameras, computers, imaging equipment or just about anything to Pearl Mini HDMI encoder. Standard and custom resolutions up to 1920×1200 from SDI, HDMI, USB, and H.264 network-based SRT and RTSP sources are accepted.

  • 1x 3G SDI
  • 2x HDMI 1.4a
  • 2x USB 3.0 (UVC/UAC)
  • RTSP (H.264)
  • SRT

Video output

Send an HDMI feed of your switched program to projectors for front-of-house presentations, display walls, or monitors for confidence monitoring. Share the program output or just an individual input source.

  • 1x HDMI 1.4a
  • SRT

Network

Connect to the network over Ethernet.

  • 1x 10/100/1000 Ethernet port (RJ45)

Audio inputs

Mix embedded audio from SDI, HDMI, or USB video sources with audio from XLR microphones and professional mixers with individual input gain controls. Confidently monitor audio levels with on-screen VU meters and headphones.

  • 2x XLR (L/R stereo pair or mono, balanced/unbalanced mic and line level signals +4.0 dBu up to 12.3 VRMS +24 dBu). Phantom optional
  • 2x 1/4″ TRS (L/R stereo pair or mono, balanced/unbalanced line level signals +4.0 dBu up to to 12.3 VRMS, +24 dBu)
  • 2x RCA (L/R stereo pair, -10 dBV consumer line-level)
  • 1x 3.5 mm (stereo/unbalanced for electret microphones)

Audio output

Connect headphones to the front-mounted 3.5 mm audio jack and monitor audio levels with on-screen VU meters.

  • 1x 3.5 mm audio jack

Plug and play, or tweak to perfection

Pearl Mini HDMI encoder is ready to use out of the box. Connect video sources directly to the HDMI inputs and start recording those right away using the intuitive touch screen. Or dig into the control interface and create a truly custom video presentation experience for your viewers.

Intuitive touch screen and One Touch start

Even unexperienced operators can control recording and streaming on Pearl Mini with confidence. One Touch lets you start/stop recording and streaming with a simple tap of the screen. Conveniently monitor your inputs and switch at the same time.

Epiphan Live™

Switch your live program and instantly see the results using Epiphan Live.

API and RS-232

Comprehensive HTTP/HTTPS and RS-232 APIs for third party integrations.

Remote login

Login to your Pearl Mini hardware encoder securely from anywhere over an Internet connection. Quickly take control of Pearl Mini for remote rescue troubleshooting, support technicians in the field, control recording, switching, and more.

Web-based UI for advanced control

From the web-based Admin panel, set up your channels and recorders, select custom resolutions and streaming options, configure security features like 802.1x, monitor system health, and more.

Local Admin panel

No need to bring along a laptop to configure Pearl Mini. Connect a USB mouse, keyboard, and HDMI monitor for easy Admin panel access anywhere, anytime. You can even use a touch screen monitor.

Integrate with your Crestron System

Integrate Pearl Mini video encoders more easily into Crestron AV systems using the Crestron-developed Control Module for Pearl. The bulk of the coding already is done. Build upon the Crestron driver’s existing code base for secure, API control over HTTP or HTTPS.

Comprehensive CMS support including Kaltura and Panopto

Full API integrations provide an effortless lecture capture and enterprise communication setup experience. Simply register Pearl Mini with your CMS to start using the video encoder for scheduled, multi-camera VOD events, ad hoc events, and webcasting without complicated programming.

Secure live streaming and control

Stream securely using the latest protocols. Pearl encoders support Secure Reliable transport (SRT) with end-to-end 256 bit AES encryptions, HLS and MPEG-DASH over HTTPS, as well as Real Time Messaging Protocol Secure (RTMPS). And enjoy worry-free deployment in your enterprise network with support for 802.1x certificate authentication and HTTPS for encrypted admin access.

Digital certificate management

Pearl Mini supports PEAP, EAP-TLS, and EAP-TTLS authentication access control methods on 802.1x networks using passwords, usernames, and digital certificates. Easily upload and manage digital certificates on Pearl Mini using the Admin panel.

Role-based access control and LDAP support

Login to Pearl Mini with administrator, operator, or viewer privileges. LDAP authentication support on Pearl Mini lets you define domain name (DN) groups to assign user roles in bulk so users can login with their LDAP credentials.

Secure streaming

Get end-to-end secure streaming with up to 256 bit AES encryption using SRT or encrypt content over TLS/SSL connections using RTMPS. Use HLS and MPEG-DASH to secure live streaming over HTTPS.

HTTPS and SFTP secure data transport

Securely access the Admin panel and configure Pearl Mini over an HTTPS connection. Encrypt and send sensitive recordings from Pearl Mini to offsite SFTP servers using Automatic File Transfer.

Epiphan Video Hard Carry Case
Hard Carry Case

Hard Carry Case for Pearl Mini
[EPI-ESP1468]

Memory Cards

Angelbird Match Pack for Panasonic EVA1
Angelbird Match Pack for Panasonic EVA1

Match Pack for Panasonic EVA1 - Dual AV PRO SDXC V90 128GB

Angelbird Match Pack for Panasonic EVA1
Angelbird Match Pack for Panasonic EVA1

Match Pack for Panasonic EVA1 - Dual AV PRO SDXC V90 256GB

Angelbird Match Pack for Panasonic GH5 / GH5S
Angelbird Match Pack for Panasonic GH5 / GH5S

Match Pack for Panasonic GH5 / GH5S - Dual AV PRO SDXC V90 64GB

Angelbird Match Pack for Panasonic GH5 / GH5S
Angelbird Match Pack for Panasonic GH5 / GH5S

Match Pack for Panasonic GH5 / GH5S - Dual AV PRO SDXC V90 128GB

Angelbird Match Pack for Panasonic GH5 / GH5S
Angelbird Match Pack for Panasonic GH5 / GH5S

Match Pack for Panasonic GH5 / GH5S - Dual AV PRO SDXC V90 256GB

Wise Advanced SD1-128U3
Wise Advanced SD1-128U3

128GB SDXC UHS-I Memory Card

Wise Advanced SD1-64U3
Wise Advanced SD1-64U3

64GB SDXC UHS-I Memory Card

Wise Advanced SD2-128U3
Wise Advanced SD2-128U3

128GB SDXC UHS-II Memory Card

Wise Advanced SD2-64U3
Wise Advanced SD2-64U3

64GB SDXC UHS-II Memory Card

PTZ Remote Cameras

Panasonic AW-UE4K
Panasonic AW-UE4K

Wide-angle 4K PTZ with IP streaming - Black

Panasonic AW-UE4W
Panasonic AW-UE4W

Wide-angle 4K PTZ with IP streaming - White

How do I control Pearl Mini?

or confidence monitoring and easy switching, recording, and live streaming control, you can use Pearl Mini’s touch screen or Epiphan LIVE, which is a tablet and mobile friendly web interface designed for easy control of your Pearl Mini. And secure remote login allows you to control your Pearl Mini from just about anywhere there’s access to the Internet.

How do I configure Pearl Mini?

Pearl Mini is ready to use right out of the box! Plug in a source into the back of Pearl Mini and you can capture, stream and record right away! For additional configuration, use the web-based Admin panel interface on the same local network as your Pearl Mini. With secure remote login, you can access the web-version of the Admin panel from just about anywhere there’s Internet access to do rescue troubleshooting and channel configuration.

The touch screen lets you control switching for Pearl Mini’s video mixer, load saved configuration presets and perform recording or streaming control.

Advanced users can use Pearl’s HTTP or RS-232 APIs to integrate with larger systems.

Is remote login secure?

Yes! A secure propriety tunnel over port 443 is used to access the Internet so you can do rescue troubleshooting, recording control, and even channel configuration from just about anywhere there’s access to the Internet.

How many sources can Pearl Mini capture?

Pearl Mini can encode multiple Full HD 1080p programs at a time. Within your program(s), you can use multiple cameras and sources connected to Pearl Mini’s two HDMI ports or 3G-SDI port.

What codecs does Pearl Mini use?

Pearl Mini currently supports AVC video encoding (e.g. H.264 and MJPEG codecs) for encoding at all resolutions up to Full HD 1080p

Can I plug my USB web camera into Pearl Mini?

Yes. You can connect one USB web camera or audio device to either of the two USB 3.0 (UVC/UAC) ports on the rear panel.

Can Pearl Mini switch, record and stream over a Local Area Network (LAN) or is an Internet connection needed?

Pearl Mini does not need a LAN or Internet connection to capture and record video. The user-friendly touch screen displays the video encoder’s stream for confidence monitoring and provides a fast and easy way to apply configuration sets, control switching or recording, and view system information. If connected to the Internet or a LAN via an Ethernet cable, Pearl Mini provides a web-based control interface for configuration and operation.

Live streaming over a private LAN is a great idea for employee training and it’s simple to do using Pearl Mini. If you want to stream to a wider audience on platforms like YouTube or Facebook, you’ll need a network connection with Internet access; otherwise, your viewers or CDN won’t be able to access your live stream.

Secure remote login gets you access to the web-versions of the Admin panel and Epiphan Live so if you want, you can remotely control recording and so much more from just about anywhere there’s Internet access.

Quick guide to lecture capture

There’s nothing mystical about recording, streaming and sharing lectures with students. In fact a full distance learning system can be designed and installed in weeks. It starts with three simple steps: 1. Lecture Theatre Camera Use a professional camera with a zoom lens that you can control remotely. With this sort of (PTZ) camera, you can position it anywhere, including fixed to the ceiling in an inverted position. For now, the camera can be just zoomed in on the lecturer. When there’s an audience, it can zoom out and pan to capture the whole room. There’s a broad selection of professional models that deliver fantastic results in dark rooms and sun-lit halls.

Preparing for distance learning: a quick guide to lecture capture devices for universities

The UK government has challenged universities to deliver high quality online learning resources for under-graduates studying remotely. With limited time available to specify, install, integrate technology and train staff, there is pressure to select equipment that balances functionality with ease of use.

Preparing for distance learning: a quick guide to lecture capture cameras for universities

Enforcement of social distancing is expected to continue well into the Autumn. This is of particular concern for university students who may find student accommodation closed and lectures limited to 30-40% capacity. So, how can university education continue? The natural answer is online.

Sharing Worship Events to a Worldwide Audience

Streaming has long been associated with worship outreach in America, the middle east and Africa. The UK and Europe are now following suit with the faithful viewing live and recorded worship events online via Facebook and YouTube channels. So what options are available, and can it be easily set up by volunteers? Record and Upload You can choose to record an event ahead of time and upload an MP4 video file to Facebook or YouTube. Most video is streamed at 720p so set your camera to record at this video standard.

Zoom: upping your video conferencing game

There’s an awful lot more content being produced on Zoom. Over the last week as gym instructors, chefs and teachers have been flocking to the Zoom video conferencing platform to communicate with audiences worldwide. The typical kit being used is a laptop, phone or iPad. The typical result is tinny audio with muffled voices, slightly blurred video and a really distracting, busy background. Let’s not kid ourselves. We’re not going to get broadcast results in a flash. But there are three simple steps we can all take to improve matters no end.

Video Streaming Solutions - Beginner's Guide

Stream it live to anywhere from anywhere The simplest way to deliver content live to staff, students, customers and service users is via YouTube Live or Facebook Live. There are lots of ways to produce and stream professional looking video. Our technical team can advise you on the best solution for your needs – give us a call on 01457 851000.

New launches at ISE 2020

Here's an overview of our vendors exhibiting at ISE 2020. Please call us on +44 (0)1457 851000 if you would like to book a stand tour with one of our manufacturers. BLACKMAGIC DESIGN HALL 3, STAND C140 The Video Assist 12G 5” and 7” monitor recorders are now shipping. The original HD versions were incredibly popular with AV technicians who wanted to verify SDI and HDMI feeds and check waveform levels. For production teams, their 4K HDR capture makes them a superb on-camera SD card recorder. The ATEM Mini is a very small, cost-effective 4 channel HDMI video switcher with streaming output. Great as a portable mixer or a signal switcher, it’s being adopted by everyone from conference producers to AV technicians looking for simple HDMI switching.

Holdan adds Epiphan Video to its portfolio

Epiphan Video has appointed Holdan as its UK & Ireland distributor for the full range of Epiphan’s live capture and streaming technologies. As the leading technology distributor for the professional video and broadcast markets, Holdan will work alongside Epiphan to enhance reseller support and to develop new opportunities in corporate AV, education and public sector video.

Firmware 4.11.0 Update

  • Assign select administrator-level functions to operators, like channel setup, networking, configuration presets, and more.
  • Update NDI on Pearl-2 to NDI version 4.1. (Pearl-2 only)
  • Monitor AFU file uploads and manual file transfers to USB drives using the touch screen and the Admin panel; as well as cancel USB file transfers using the Admin panel.
  • Support for Kaltura's lecture capture plus live event type.

Firmware 4.9.1 Update

  • Kaltura users can enter more ad hoc event details like a description, categories, and tags when creating an ad hoc event.
  • You can now set how often the Admin panel polls Kaltura to update the events listed on the Events page.
  • Panopto users can now authenticate for ad hoc events using credentials defined on third party identity providers such as Canvas and identity providers that support SAML 2.0.
  • Panopto users can select the folder location where their recordings are uploaded in Panopto for ad hoc events.
  • There's a new setting to automatically log users out of their CMS session after their ad hoc event ends.
  • We've added international character support in channel names, layout names, video and audio input names, text overlays, and in the name of recorded files - including the following:
    • Western European/Nordic languages: Danish, Dutch, English, French, German, Icelandic, Italian, Norwegian, Portuguese, Spanish, and Swedish.
    • Central/Eastern European languages: Bosnian, Croatian, Czech, Hungarian, Polish, Romanian, Slovak, and Russian.

Firmware 4.9.0 Update

  • Full Panopto integration to use Pearl as a remote recorder for multiple-source scheduled, recurring, and unscheduled ad hoc video recordings and webcasts with easy user authentication using the touch screen.
  • For Kaltura, we added multiple source ad hoc VOD recording and webcast creation directly from the touch screen with user authentication, plus added support for multiple source ad hoc recordings.
  • You can now toggle between temperature/CPU load on the touch screen.
  • The EDID of each input is verified when Pearl is powered on.
  • We improved support for the 4:2:2 color space on 12G and 6G SDI. (Pearl-2)
  • USB tethering feature has been removed.
  • Some minor changes to the Admin panel arrow key and AFU controls.

Download the latest Firmware and Software

  • Pearl Mini
  • 1 x Power Supply
