HRS-30

HD recorder and monitor in one

Product Code: DATA-HRS30-0TB

Suggested Retail Price £1,995+VAT

Where to buy Videos

Kit List

View your Kit List
  • Removable hard drive
  • Support NTFS format, no 2GB/4GB file limitation
  • HD/SD SDI input, output and loop thru with embedded audio
  • HDMI output with embedded audio
  • Video resolutions:
    - 1920x1080 23.97p/24p
    - 1920x1080 50i/59.94i/60i
    - 1280x720 50P/59.94P/60P
    - 720x576i or 720x480i
  • SD mode recording:
    - Selectable 8,15,30 or 50 Mbps Long GOP 4:2:0 or 4:2:2
    - 100/125Mbps i-frame 8-bit 4:2:2
  • Recording file formats: MXF/OP1A, MOV quick time*
  • V mount Battery and Anton Bauer battery support.
  • Wide view angle colour TFT LCD display for OSD operation
  • 10.1" 16:9 monitor resolution : 1280 x 800 dots.
  • 10.1" Dot pitch : 0.0565(W)× 0.1695(H)mm

10.1" monitor features

  • Internal colour bar
  • Blue only
  • Audio indicator
  • Safe area
  • Time code display
  • Colour temperature adjustment
  • NTSC/PAL auto switching

N.B. HRS-30 cannot charge the V-mount battery.

The HRS-30 is a portable recorder with an integrated 10.1" monitor that can be used as a field recorder and also a playback system.

The HRS-30 records from both HD and SD video equipment via HD/SD-SDI and supports 1080i, 720p, 576i, 480i video formats, providing a choice of recording formats in MEPG-II Long-GOP or intra-frame (i-frame) with 4:2:2 colour sampling.

The recorded MXF/OP1A file format is compatible with a wide range of NLE and play out systems.

Recorded files are stored to a removable caddy which is compatible with 2.5" SSD drives.

Datavideo HE-2
HE-2

Removable HDD/SSD Carrier for HRS-30
[DATA-HE2]

The perfect breakout assistant

Datavideo's DAC-75T is designed to convert video signals from VGA, HDMI, SDI to HDMI or SDI. With touchscreen control, it's a great ally for venues, conference teams and AV rental teams that need to be ready for whatever the presenter needs to project.  DAC-75T makes childplay of connecting your source to a screen or projector. The DAC-75T does upscaling, downscaling and standards conversion for any HDMI, VGA or SDI device to any HDMI or SDI screen or projector. RCA inputs allow audio to be embedded to the output of the video signal for recording purposes.

Datavideo joins hands with the stars at Regal Con 2015

A complete live video solution for Regal Con 2015

  • 1 x HRS-30
  • 1 x AD Switch 12V
  • 1 x Hard Drive Fixed Module
  • 4 x Screw
  • 1 x USB Light
  • 1 x SATA to USB Cable
  • 1 x 2.5” HDD Bag
