PTZ Remote Cameras

BirdDog Eyes P400 | 4K NDI PTZ Camera with Professional Level Colour Control - White


Eyes P400

4K NDI PTZ Camera with Professional Level Colour Control - White

Product Code: BDP400W

Suggested Retail Price £3585+VAT

View Product Variations Where to buy Videos

Have a question about this product or want to request a demo?

Contact Our Technical Team Contact Our Education Team

Kit List

View your Kit List


BirdDog General Warranty Terms and Conditions

  • 4K NDI Camera with Professional Level Colour Control
  • 4K CMOS Backlit Sensor
  • NDI, 6G-SDI and HDMI outputs
  • 20x optical zoom
  • Available in Black or White

Stunning 4K NDI® with incredible colour tools

P400 features stunning 4K resolution NDI and allows chroma subsampling in your choice of 4:2:0 or 4:2:2. It teams up BirdDog’s custom NDI® silicon chip, a 4K Sony CMOS Backlit sensor, and a true Sony Image Module. P400 includes professional-level colour tools including Colour Matrix control, Black level, Gamma including 512 pre-set gamma positions.

4:2:2 4K Video

P400 debuts the world’s first 4K NDI with chroma subsampling at 4:2:2 which can be decoded natively in hardware by BirdDog’s 4K Family of NDI Encoders and Decoders. If decoding with a 4:2:0 receiver the stream will automatically serve 4:2:0 and this is what will be decoded. Think of it as an automatic and virtual handshake.

Adaptive bit rate

Full NDI® is a variable bit rate codec. In normal circumstances BirdDog recommends allowing around 140Mbps in HD, or 6 streams per 1GbE cable with some headroom. In 4K it is recommended to allow around 300Mbps or 3 streams with some headroom to allow for any unforeseen spikes.

With BirdDog’s tools you can select the bit rate to suit your bandwidth and requirements. In both HD you can slide between 80-180Mbps and in 4K you can select the data rate to be anywhere between 60 and 360Mbps.

BirdDog Cam Control

BirdDog Cam Control allows full access to the entire colour matrix, black levels, and even the gamma to be able to shade your P400 professionally. Right click to view camera full screen on a secondary monitor to really dial in the look you want and then copy the settings to colour match cameras in seconds.

Incredible low light performance

In low light conditions the camera automatically switches from day to night mode, removing the IR-cut filter to boost sensitivity for clear pictures in near-darkness.

Triple output. NDI, 6G-SDI and HDMI

With NDI®, 6G-SDI, and HDMI simultaneous outputs, the P400 is ready to go live with your full NDI® workflow today or if you are still in an old school SDI workflow you can use as an SDI camera and ease your way into the world of NDI®. lets you eliminate the need to add frame buffers.

Superfine Robotics. Precise control at your fingers

P400’s robotics are precise and sensitive. Wind down the panning and tilting speeds to create super professional shots that are dramatic, or crank up the speeds for high action sports to allow you to follow the movements.

20x Optical Zoom

The 20x optical zoom offers a bright F2.0 aperture with a super smooth and fast zoom. Transition from wide to tele and recall pre-set positions quickly and with super fine precision. The incredible optical zoom function makes P400 perfect for sports such as football, baseball, hockey, ski fields, basketball, soccer, and more.

Tally light

NDI has tally information built into the metadata so when P400 is connected to an NDI enabled switcher the tally light on the front of the unit to ensure your on-air talent will always know which camera is live.

PoE or DC Power options

P400 can be powered by Power over Ethernet (PoE+) for single cable operation that can carry Video, Audio, Power, Tally, and Intercom or you can choose to use the included power adapter.

PTZ Keyboard

Combine P400 with the BirdDog PTZ Keyboard and you have total control of all functions remotely. PTZ Keyboard is a full featured PTZ Keyboard that can control up to 255 PTZ cameras on a single network so can scale to even the most complex installations. PTZ Keyboard can control P400 over NDI® or by RS422 / RS232 when using in SDI mode.

Download the free BirdDog RESTful API and program your own automation for all BirdDog hardware endpoints, including cameras.

  BirdDog Eyes P100
Eyes P100
BirdDog Eyes P200
Eyes P200
BirdDog Eyes A200
Eyes A200
BirdDog Eyes A30
Eyes A300
BirdDog Eyes P40
Eyes P400
BirdDog P4K
Description Indoor HD camera with NDI, HDMI & SDI outputs Super-zoom indoor HD camera with NDI, HDMI & SDI outputs Outdoor HD camera with HD NDI & SDI All-weather HD NDI/SDI camera with 30x zoom 4K PTZ with professional colour management tools 4K NDI PTZ Camera with Professional Level Colour  Broadcast-level 4K PTZ with superb images in all lighting conditions


Image Sensor 1/2.86" CMOS 2.2MP 1/2.8" CMOS 2.13MP 1/2.8" CMOS 2.13MP 1/2.8" CMOS 2.13MP 1/2.5 inch CMOS 8.5MP 1.0-type back-illuminated Exmor R CMOS sensor 14.2MP
Lens 4.7 - 47mm 4.3 - 129mm 4.3 - 129mm 4.3 - 129mm 4.4-88.4mm Zeiss Vario-Sonnar T lens
9.3 - 111.6mm
Optical Zoom 10x 30x 30x 30x 20x 12X
12x Digital Zoom Yes Yes Yes Yes 30x in 4K, 40x in Full HD 18X zoom at 4K, or 24X zoom at FHD.
Horizontal Angle of View 69.9º(W) - 6.43º(T) 63.7º(W) - 2.3º(T) 63.7º(W) - 2.3º(T) 63.7º(W) - 2.3º(T) 70.2°(W) – 4.1°(T) 64.6°(W) – 6.1°(T)
Aperture F1.6(W) - F3.0(T) F1.6(W) - F4.7(T) F1.6(W) - F4.7(T) F1.6(W) - F4.7(T) F2.0(W) – F3.8(T) F2.8(W) – F4.5(T)
Wide Dynamic Range - - - - Yes Yes
ND Filter - - - - Yes Yes
Image Stabiliser - Yes Yes Yes Yes Yes
Colour Matrix Yes Yes Yes Yes Yes Yes
Gamma - 72 Gamma Positions 72 Gamma Positions 72 Gamma Positions Standard, Straight, 512 pattern
Gamma Level / Black Level - - - - Yes (15 step) / Yes (97 step)


SDI Yes Yes Yes Yes Yes (6G) Yes (6G, dual 3G)
HDMI output Yes Yes - - Yes Yes
1080i, 1080p & 720p Video Formats Yes Yes Yes Yes Yes Yes
4K (up-to 30fps) - - - - Yes Yes
3.5mm Audio In | Out Yes Yes Yes Yes Yes Yes
Dante Support Yes, with optional hardware licence


Full NDI Yes Yes Yes Yes Yes Yes
NDI – discovery, configuration and control Yes Yes Yes Yes Yes Yes
Full control via Web/Mobile UI Yes Yes Yes Yes Yes Yes


Operating Temperature -10 to +50 (ºC) -10 to +50 (ºC) -40 to +60 (ºC) -40 to +60 (ºC) -10 to +40 (°C) -10 to +40 (°C)
IP67, corrosion resistant treated housing - - Yes Yes - -
Wind load durability <up-to60m/s - - - Yes - -


NDI IP PTZ Control Yes Yes Yes Yes Yes Yes
2x RJ45: RS232/RS422/RS485 Yes Yes Yes Yes Yes Yes
VISCA / Pelco D Serial Control Protocol Yes Yes Yes Yes Yes Yes
Tally Light - Yes - - Yes Yes (front and back)
Free Cam Control Yes, remote shading and colour matching


Power Input 12v DC, PoE+
(IEEE 802.3at)
12v DC, PoE+
(IEEE 802.3at)
AC 24v (Option)
PoE 97W Ready (BirdDog PoE 97W Injector needed, optional)
AC 24v (Option)
PoE 97W Ready (BirdDog PoE 97W Injector needed, optional)
12v DC, PoE+
(IEEE 802.3at)
12VDC, PoE+
(IEEE 802.3at)
Dimensions 145x145x154mm 160x178x220mm 210x210x333 180x180x423mm 142x159x217mm 165x196x247mm
Weight 1.0Kg 2.0Kg 5.5Kg 10.2Kg 2.7Kg 3.4kg
