Atomos NEON 17 | 17inch 1920x1080 Resolution, 16:9 Aspect Ratio Monitor

Atomos

NEON 17

17inch 1920x1080 Resolution, 16:9 Aspect Ratio Monitor

Product Code: AO-ATOMNEO171

Suggested Retail Price £2,799+VAT

Where to buy Videos

Stock status: In Stock; available from resellers

Kit List

View your Kit List

Technology Guides


  • 17" 1920x1080 Resolution, 16:9 Aspect Ratio Monitor
  • 1000Nits Full Array Local Dimming with 1000nits Full screen brightness and 1600Nits HDR peak brightness
  • Colour Gamut DCI-P3 Coverage, D65 Calibrated White Point
  • 3D LUTs (.cube format)
  • Anamorphic squeeze, image anaylsis scopes, focus and exposure assist tool
  • Log/RAW to HLG, PQ output
  • Rear 100x100 Vesa Mount with mount, 1/4"" / 3/8” mounts top, bottom and sides
  • Master Control Unit (MCU) feature HDMI 2.0b I/O and includes the AtomX SDI module with 2 x configurable 12G SDI BNC
  • Atomos Remote – (REQUIRES APPLE iOS Device with iOS12 or above for Atomos Remote APP)

Providing certainty of image

NEON 17 and NEON 24 are precision on-set and in-studio 4K HDR production monitors that also record and play back. Featuring full array local dimming (FALD) to achieve1000nit/cdm2 full screen brightness, 0nit / cdm2 Black point. With wide gamut DCI P3 coverage, built in LOG transforms for HDR monitoring and custom 3D LUTs for SDR the NEON series provide accurate monitoring for either production or post.

Full screen brightness with deep blacks and wide colour gamut

Our flagship NEON 24 utilizes a combination of high quality 17:9 4k DCI resolution, true 10-bit panel fidelity with full array local dimming back light that delivers 0nit deep blacks, 1000nits HDR peak brightness.

Colour Managed Display Pipeline

The AtomHDR engine provides the ability to accurately manage your input and display Gamma/Gamut. Selectable monitor modes allow you to work in either SDR or HDR project settings, that match both camera acquisition settings, or defined delivery standards including Rec.709, Rec.2100 HLG or ST.2084 PQ. NEON provides native accurate colour with DCI-P3 coverage. Wide colour gamuts, such as BT.2020, are accurately processed by the AtomHDR engine to deliver consistent representations. Built in transforms, allow for the conversion of LOG to HDR standards or utilise 3D LUTs for SDR, to monitor with a specified look or exposure compensation. Downstream output options also provides for conversion between standards to best suit the target display with options for SDR, LUTs or HDR.

Flexible and Upgradeable I/O

The foundation of the NEON platform is a modular approach that ensures the I/O of the monitor is both easy to maintain, replace and ultimately upgrade without having to take the panel out of commission. The Master Control Unit (MCU) is the brain of the NEON with support for HDMI 2.0 for both in and loop out, which provides support for video input at 4096 x 2160 4k DCI at up to 60p.

The MCU firmware is easily upgradable and allows the upload and storage of up to 8 x 3D LUTs in its internal memory or can use a 2.5” HDD or SSD to store an unlimited library that can easily be uploaded to the NEON via the AtomRemote App** on iOS. The MCU offers a second level of expansion via the Xpansion port and NEON includes the AtomX SDI module which provides 2 x 12G SDI. The configurable ports allow for input of up to 4k60p video.

** Available from end November 2020.

As standards and interfaces develop, both the MCU and Xpansion port modules can be changed and upgraded to meet your needs without needing to change the entire monitor.

Record and Playback modes

Connect cameras or any video source via SDI, supporting up to 4K DCI 60p via 12G or Dual 6G or lower resolutions and frame rates via 1.5/3G SDI up to 2Kp60 with up to 12 channels of embedded audio. Recordings can easily be played back and reviewed without needing to off load media or take the camera out of record mode. HDMI signals without HDCP are supported up to 4k60p or HD 120fps with up to 8 channels of audio and detection of HDR info frame to automatically match the input signal type. 10bit 422 recordings are captured to industry standard Apple ProRes of Avid DNx Codec using Scene Shot Take file naming with rich metadata in the file header that can be utilized by your NLE or MAM system to asset orchestration.

To play back files recorded to SSD on the NEON, or SSDs from other Atomos devices, simply place the SSD in to the MCU drive slot. Clips can also be exported directly from your NLE or transcoded toProRes/DNx to be played back on the NEON.

Frame Guides and Anamorphic De-squeeze

A variety of broadcast frame guides with the option to EBU R5 Graphic and Action safe areas can be enabled. Cinematic guides are also available and can all be used alongside the anamorphic de-squeeze mode with support for 2x, 1.5x and 1.33x to allow you to match a wide variety of lenses.

App control for all essential monitoring tools

Atomos Neon - Waveform Monitors

Waveform Monitors

Offer Luma Parade, RGB parade, Vector Scope with Vector zoom to monitor levels with specific graticule scales across input EOTFs.

Atomos Neon - Pixel Zoom

Pixel Zoom

Allows operators to punch in to check shots for focus or aspects of the detail with pan and scan around the image.

Atomos Neon - Focus Peaking

Focus Peaking

Colour, Mono and edges only enable easy focus pulls or shot selection. Traditionally used on set but also ideal when reviewing shot selects.

Atomos Neon - Adjustable Zebras

Adjustable Zebras

Exposure check and analysis.

Atomos Neon - False colour

False colour

Exposure check and analysis. can be used in both production and post to set exposure or identify areas that may need to be painted down with power windows.

Atomos Neon - Audio at a glance

Audio at a glance

Audio PPMs for all embedded channels with headphone monitoring of selected stereo pair. Additional input can be via 3.5mm jack located on the MCU.

Atomos Nextorage AtomX SSDmini
Nextorage AtomX SSDmini

Compact form factor SSD - 1TB
[AO-ATOMSSD01T]

Atomos Button Bar Remote
Button Bar Remote

Button Bar Remote Control Unit
[AO-ATOMBBRCU1]

Atomos Nextorage AtomX SSDmini
Nextorage AtomX SSDmini

Compact form factor SSD - 500GB
[AO-ATOMSSD05G]

Memory Cards

Angelbird AtomX CFast Adapter
Angelbird AtomX CFast Adapter

CFast to AtomX SSDmini ADAPTER

Midwich Live from the AV Awards

On Friday the 5th of November Holdan were once again part of one of the biggest celebrations of the year and this one didn’t have a single firework go off. Why you ask? Well, we’re not talking Gunpowder Plots here, we’re of course talking about the highly anticipated AV Awards 2021 in Battersea, London.

  • NEON 17 Monitor
  • NEON Master Control Unit
  • 2 x Feet (inc. mount screws x 2)
  • NEON Quick Start Guide
  • 1 x Master Caddy II (inc. screws)
  • 19V AC Power Adapter with mount cage
  • AtomX SDI Expansion Module
  • Monitor Protective Sheath
  • MCU Protective Sheath
  • Hex Wrench
