Video Wall Processor

C3-540 CORIOmaster

tvONE

C3-540 CORIOmaster

Dynamic Video Display System

Product Code: TV1-C3-540-1001

Suggested Retail Price £11,665+VAT

Where to buy

Kit List

View your Kit List

CORIOmaster is available in three different form factors. Please note that each offers identical power for incredible effects, high quality scaling and real-time processing.

CORIOmaster is a dynamic product used to create video walls with no limit to creativity. Mix and blend different screen types, sizes and orientations - even monitors in motion.

Built to order; typically ready to ship within 7 working days



FREE CORIO Training

tvONE has a fantastic training programme at its Maidenhead HQ. Click here for details.




CORIOmaster Masterclass

Get up and running with the tvONE CORIOmaster

CORIOmaster - Transitions

Window and Source Transition effects are now available through CORIOmaster & CORIOmaster mini's control software, CORIOgrapher.

Built to order; typically ready to ship within 7 working days

  • Single or Multiple Output Layouts
  • Single or Multiple Canvases
  • Real-time 360º Output Rotation
  • Projector Off-Axis Correction w/Brightness Control
  • Output Warping for Projection on Curved Surfaces
  • Simultaneous use of Multiple Layouts and Canvases
  • One or More Windows (PIP's) on each Canvas
  • Layouts and Canvases Can Be Created Off Line and Saved for Later Recall
  • Internal Still Image Store
  • 3 Levels of User Access and Control
  • PC and Apple Desktop Software
  • Controllable by Web Browser
  • Low Power Consumption - 160w

Video Choreography Design Possibilities

  • Live Event Using Multiple Projectors
    • Edgeblending w/Side Projectors
    • Stage Monitoring
  • Video Walls
    • Number of Monitors Determined by Number of Outputs
    • Rotation of Monitors Possible using Canvas Window Rotation
  • Command & Control
    • Monitoring of Various Video Sources & Formats
  • Hospital/Healthcare
    • Distribution with Windowing to Various  Operating Rooms or other locations
    • Status Display of Video Equipment in Use

Technology Guides

C3-540 CORIO®master offers a new, more efficient approach to building video systems. Using TV One's latest CORIO®3 technology, it gives the user access to new levels of video processing power to achieve new heights of creative and dynamic video displays. All this is possible in one 4RU chassis.

CORIO®3 video processing technology allows the use of layouts which define where each output is used. Outputs can be independently rotated through 360º in real-time, without adding delay, for use in creative video wall applications. Projectors can be used off axis with brightness controls to aid in an even distribution of the projected image. Warping controls allow for projection on curved surfaces. Multiple layouts can be used at the same time or one layout can be designed to tie multiple projectors or monitors together as one large image.

Edge blending, monitor walls and multiple projectors can show any combination of inputs by setting up canvases to design each layout without the limitation of a monitor or projector dedicated to just one source input. Multiple canvases can be used at the same time to define multiple layouts to aid in choreographing a video design. To further assist functionality, multiple windows can be used to design a canvas with the capability to resize and rotate each window on the canvas which is then sent to the predefined layout. The same canvas can be sent to more than one layout design. This allows for duplication in more than one area or used for status display on one monitor of the entire canvas.

The CORIOmaster also includes a multi-viewer to monitor the inputs to aid in previewing the sources during live events or used as a status monitor in various types of installations. Graphic images can be loaded into the CORIOmaster to use as backgrounds as well as for use on each canvas.

Control of the CORIOmaster is provided by a multiplatform software package that provides an intuitive way of setting up layouts and defining the canvas to be used for each layout. Presets can be saved and recalled. Changes can be made to the canvas and then transferred to the layout.

The flexibility to use various input formats and the ability to up, down, and cross covert those signals on the outputs of the CORIOmaster to various displays and projectors of any format allow for easy installation without the use of multiple pieces of equipment to accomplish the same task all accomplished in a 4RU chassis.

The CORIOmaster is high power in its capabilities, but low in its power consumption. It typically requires only 160 watts, fully loaded. A traditional video system that performs the same tasks can consume ten times as much energy. Over its life, that is a lot of savings.

Physical Properties
The C3-540 has 16 Uuniversal AV Module slots available and the CORIOmaster automatically recognizes the modules inserted as either input or output modules. There is no dedicated input or output slots when using 2-Channel DVI-U or 3G-SDI modules. This flexibility allows end user configurations to be based on their own needs. Additional DVI-U or 3G-SDI modules can be added later in spare slots without having to reset the unit. All AV modules are hot swappable and recognized for immediate auto configuration.

CORIOmaster also provides independent Up, Down and Cross conversion for every output between a variety of analog and digital video formats thru 3G-SDI and WUXGA. The modules selected determine what format will be accommodated and the matrix size. Signal parameters of the incoming video may be adjusted. All settings are stored in non-volatile memory and are retained even when power is switched off. User defined presets are also available to customize settings for various applications.

All the functions can be controlled via serial connection via RS-232/422/485, USB or IP. A front panel LCD option makes direct setup easy. The unit is housed in a standard 4RU rackmount case and features an optional redundant hot swappable internal PSU and power inlet.

Advanced Features
The CORIOmaster includes advanced Digital Flicker Elimination circuitry and high 4:4:4 full bandwidth sampling rate ensures crisp, clear images, while full bandwidth chroma sampling ensures faithfully reproduced, high resolution colors. Pixel Level Motion Adaptive Diagonal Interpolation and Noise Reduction ensures high quality de-interlacing of PAL, NTSC and 1080i signals. 3:2 Pull-down ensures proper 24 fps film extraction from NTSC and 1080i sources.

Integral audio switching is provided to route audio from the DVI (HDMI-compatible) input or SDI input to the DVI and SDI outputs. An optional Audio Module can provide AES and analog or digital I/O breakout capabilities as well as audio delay and can link to our A2-7300 range of audio break-out units.

Software Control

The unit is provided with PC software package for simple intuitive control of the unit. Starting with the ability to set up the input and output signal requirements, the user is guided through the graphical interface in configuring the outputs into the layouts.

Once the system has been configured your visual artistic talents can be unleashed by positioning, sizing, stretching and rotating windows onto the canvases. Windows can be easily layered and overlapped and layer priority of each window can be easily changed. The canvases can be designed off-line and then checked and adjusted when connected to the unit.

By use of presets, the different arrangements of the windows can be recalled live by use of simple commands from third party controllers.

DVI-U
The DVI-U universal interface utilizes a single DVI-I connector to provide the following signal formats: HDMI, DVI-I, plus analog YUV, YPbPr, RGBHV, RBBS, RGsB, Y/C and Composite Video. A variety of adapters are available to convert from DVI-I to other connectors.

DVI-U Modules
The system features the following types of modules for the inputs and outputs. All modules only use 1 AV Slot.

  • DVI-U Universal Input Module - 2 Inputs
  • DVI-U Universal Scaling Output Module - 2 Outputs


The high resolution DVI-U outputs are selectable as virtually any PC or HDTV resolution. Our exclusive AutoSet feature takes the hassle out of setup by automatically sizing and positioning the computer image to fit exactly on the video screen. NTSC, PAL, PAL-M, PAL-N, SECAM standards are supported.

SDI Modules

  • 3G/HD/SD-SDI Input Module - 2 Inputs
  • 3G/HD/3G-SDI Output Scaling Module - 2 Outputs
  • HD/SD-SDI Input Module - 4 Inputs
  • HD/SD-SDI Output Scaling Module - 4 Outputs


Note - Use of the four-output modules does impose some slot restrictions.

Data Modules
Tally Module - Uses 1 of 3 Data Slots Provided

Audio Interfaces
The optional CM-AUD-8IN-8OUT Audio Interface Module allows connection to any of the following optional external breakout units via HD-44 Connector.

  • A2-7312 Converts AES-3id I/O to 16x BNC Connectors 8x AES-id In and 8x AES-3id Out
  • A2-7302 Converts AES-3id I/O to 16x XLR Connectors 8 AES Stereo In and 8x Stereo Out
  • A2-7342 Converts AES-3id I/O to 16x XLR Connectors 4x Analog Stereo In & 4x Analog Out
  • A2-7322 Converts AES-3id I/O to Analog Stereo on Terminal Blocks, 8x Analog Stereo In and 8x Analog Stereo Out, Balanced or Unbalanced

Future Modules
Additional types and formats of Video, Audio and Data Modules will be added in the future. Please check our websites for the latest list.

tvONE HDBaseT CORIOmaster Scaled Output Module
HDBaseT CORIOmaster Scaled Output Module

2 x HDBaseT Out 1 x Ethernet Input (single Cat.5e/6) for CORIOmaster

tvONE 3G-SDI CORIOmaster Scaled Output Module
3G-SDI CORIOmaster Scaled Output Module

2 x SDI Output Card with scaling (2x 3G/HD/SD-SDI via BNC) for CORIOmaster

tvONE CM-3GSDI-MON-2OUT
CM-3GSDI-MON-2OUT

2 x SDI Output Card with scaling (2x 3G/HD/SD-SDI via BNC)

tvONE 4K30 Scaling Output Module
4K30 Scaling Output Module

Output Module 4K with Scaling1 x HDMI up to 4K30/UHD for CORIOmaster

tvONE DVI-I CORIOmaster Scaled Output Module
DVI-I CORIOmaster Scaled Output Module

Dual DVI-U Output Card with scaling (2x DVI-U via DVI-I Connectors) for CORIOmaster

tvONE Streaming Media and 4K Playback Module
Streaming Media and 4K Playback Module

Input Module, Dual Channel Decoder via RJ45, 4K File Playback via USB 3.0 & 16GB Internal SSD for CORIOmaster

tvONE HD - SD-SDI CORIOmaster Input Module
HD - SD-SDI CORIOmaster Input Module

4 x SDI Input Card (4x HD/SD-SDI via BNC) for CORIOmaster

tvONE HDBaseT CORIOmaster Input Module
HDBaseT CORIOmaster Input Module

Input Module 4K HDBaseT, 2 x HDBaseT up to 4K60 for CORIOmaster

tvONE CM-DVIUMON2OUT
CM-DVIUMON2OUT

Monitoring Card (2x DVI-U via DVI-I Connectors)

tvONE A2-7302
A2-7302

Digital Audio Converter Box for C2-7300 Series

tvONE 3G-SDI CORIOmaster Input Module
3G-SDI CORIOmaster Input Module

2 x SDI Input Card (2x 3G/HD/SD-SDI via BNC) for CORIOmaster

tvONE 4K HDMI Input Module
4K HDMI Input Module

Input Module 4K 2 x HDMI (1 x 4K60, 1 x 4K30) for CORIOmaster

tvONE Universal DVI CORIOmaster Input Module
Universal DVI CORIOmaster Input Module

Dual DVI-U Input Card (2x DVI-U (DVI, HDMI, RGB/YUV, CV, YC) via DVI-I) for CORIOmaster

tvONE CM-AUD8IN8OUT
CM-AUD8IN8OUT

Audio Interface Module (8x Inputs and 8x Outputs via HD-44 Connector)

tvONE 128GB SSD Streaming Media and 4K Playback Module
128GB SSD Streaming Media and 4K Playback Module

Dual Channel Decoder via RJ45, 4K File Playback via USB 3.0 & 128GB Internal SSD

tvONE in the news at Kuwait TV Studio 160

Kuwait TV has installed a CORIOmaster controlled video wall processor in a major news studio. The $120,000 video wall was built by Gulf Apps Technical Solutions, as part of an extensive refurbishment programme at the studios.

tvONE Debuts New Video Wall Software alongside Latest Video Conversion Products at ISE 2014

tvONE will be showing a full range of industry-leading video conversion and distribution products in Hall 4, Stand R62, during ISE 2014, 4-6 February, Amsterdam RAI. Highlights include several important innovations such as the CORIOmaster mini all-in-one video wall processor, new CORIOgrapher video wall software and the recently launched CORIO®2 Universal Scaler.

CORIOgrapher v2.2

New Features

  • US6275: Global Ease In/ Out for Transitions via General Settings.
  • US0882: Wall Editor Immediate Mode to send values to Device without pressing Take.
  • US0966: Input Cropping via Window Properties Pane.
  • US0951: Undo Configuration changes/settings in Wall Editor.
  • US1137: Redo Configuration changes/settings in Wall Editor.
  • US1153: Support Undo Redo in Edge Blend Mode.
  • US1138: Undo and Redo Wall Editor Selection as part of the Revision History.
  • US6392: Prompt to do a Take when entering Immediate Mode as there might be unsent changes.
  • US6645: Change Window Snapping to snap to Display Viewable area only.
  • US0954: Test Pattern - Global on and off option.
  • US4535: Add Network Settings view (in settings)
  • US1077: When Logging in prompt to either Read, Send, or Just Connect to the Device.
  • US0889: Change and View Ethernet Network Settings via Settings Page.
  • US1129: FW/CG - Allow saving of System Settings independently to the Live Configuration.
  • US6407: Dithering: Add On/Off option to all Inputs

Defects Resolved

  • BUG FIX #802961: Setting too large a value for a windows width causes CORIOgrapher to hang
  • BUG FIX #802932: Display & Window dimensions are not correct when switching from Physical mode to Pixel mode.
  • BUG FIX #802783: Selecting a Window or Display by clicking on it causes it to move slightly.
  • BUG FIX #801842: Changes (Window location) in Physical Mode is not the same in Pixel Mode.
  • BUG FIX #802782: Variable amount of overshooting when snapping a Window to a Display.
  • BUG FIX #802882: Leaving the Wall Editor page while in Edge Blend Mode leaves the grid visible on device.
  • BUG FIX #802891: Enlarging a display in Video Wall 2 causes the Window quality to get worse on Displays associated with Video Wall 1.
  • BUG FIX #802892: Add a Display to Video Wall 2 causes Displays on Video Wall 1 to move and repositioned just off their original position.
  • BUG FIX #802631: Canvas preview on Dashboard corrupted.

Download the latest Firmware and Software

  • 1 x C3-540
  • 1 x Operations Manual
  • 1 x Power cable US, UK, Euro or AU
  • Control Software USB Flash Drive & Downloadable from Website
