Panasonic AV-HLC100 | Live Streaming Production Center



Live Streaming Production Center

Product Code: PAN-AVHLC100

Suggested Retail Price £11,312+VAT

Where to buy Videos

Kit List

View your Kit List


Warranty information available here

  • Production system based on the Tricaster Platform
  • Combined 1ME switcher, PTZ camera controller and audio mixer
  • Support of 1080/59.94p and 50p video formats
  • Support of both NDI|HX and RTMPS network protocols
  • 3D joystick supports single-handed operation with pan, tilt and zoom capabilities
  • Web Control - Control Audio Mixer and Switcher function from a PC or Tablet
  • Hot Key Customisation - Able to add/customise Hot Key operation
  • External Source for Title - Title can be used with Input Sources or can be used as a 2nd PiP
  • Save/Load Project files in the Administration Menu
  • Count down timer on Clock
  • Dimensions (W x H x D): 427 mm x 93 mm x 278 mm / 16.8 inches x 3.67 inches x 10.96 inches (excluding protrusions)

The AV-HLC100 live production center is an AV production unit from Panasonic that allows for a high-quality, professional transmission to be enabled where there are a limited number of operators available, making it a suitable option for live-streams, conferencing facilities and event/staging facilities.

Combining the functionalities found with a 1ME switcher, PTZ camera controller and audio mixer into a single device, the AV-HLC100 makes it possible for a single person to operate all functionalities within a transmission.

For PTZ camera operation, both the connection and settings can be managed via the Easy-IP connection function whilst pan, tilt and zoom operations can be performed using the large joystick.

Output format support includes 1080/59.94p and 50p in addition to a cross-conversion functionality between 1080p and 720p. Flexible transmission can also be achieved through the ability to mix embedded, line-input and mic-input audio into the video.

The AV-HLC100 also supports both NDI|HX, RTMP and RTMPS network protocols, with the latter allowing direct transmission to be made into live streaming services such as YouTube Live for example.

With a full line-up of professional integrated cameras with built-in NDI|HX support now available, the introduction of the AV-HLC100 supports a complete live production system purely over IP with a single-cable workflow that enables very low latency video, audio, PTZ control, tally and power all over a single CAT5 cable.

* NDI is a trademark of NewTek Inc.

New launches at ISE 2020

Here's an overview of our vendors exhibiting at ISE 2020. Please call us on +44 (0)1457 851000 if you would like to book a stand tour with one of our manufacturers. BLACKMAGIC DESIGN HALL 3, STAND C140 The Video Assist 12G 5” and 7” monitor recorders are now shipping. The original HD versions were incredibly popular with AV technicians who wanted to verify SDI and HDMI feeds and check waveform levels. For production teams, their 4K HDR capture makes them a superb on-camera SD card recorder. The ATEM Mini is a very small, cost-effective 4 channel HDMI video switcher with streaming output. Great as a portable mixer or a signal switcher, it’s being adopted by everyone from conference producers to AV technicians looking for simple HDMI switching.

Panasonic: 4K Handheld Camcorder Promises High Quality Images And Advanced Connectivity

Panasonic has introduced a new handheld camcorder, the first in a series set to combine advanced connectivity functionality with high end image production for broadcast and streaming applications. The AG-CX350 camcorder spearheads the series, and is the first camcorder in the industry to provide NDI | HX connectivity. This ensures smooth video transmission and camera control over IP for live events and web distribution, and means the camera can be built in to larger systems working alongside Panasonic PTZ camera systems equipped with NDI|HX and the Panasonic Live Production Center (AV-HLC100).

AV, one world, one cable, under NDI HX

What is NDI HX? Why is it taking the world by storm? Can it replace SDI and HDMI? What manufacturers are involved? When you search ‘What is NDI HX?’ on Google, you get this answer:

What's new at NAB 2018?

All the key new products from NAB 2018: Blackmagic Design, Teradek, SmallHD, CoreSWX, Panasonic, Sonnet, SLR Magic, LEDGO, more! Richard Payne, Head of Technology writes... "The NAB Show is the world's largest convention encompassing the convergence of media, entertainment and technology. The general consensus was that despite the crowds around certain stands, attendance might have been lower than previous years. Wednesday and Thursday seemed quieter, so it will be interesting to see if this is proved when the attendance figures are released. You can read our show magazine at your leisure!"

Version 7-1-200407

New Function and Functional improvement

  1. "Project" file (all setting of AV-HLC100) can be saved / loaded at Admin panel (up to 6 slots).
  2. The function to customize by assigning the keyboard shortcut operation "Hot Key" was added.
  3. "Title" signal can be used with the external input sources and it can be used as a "PinP" source.
  4. Count Down timer was added as a part of Clock function.
  5. The menu screen of PTZ cameras can be operated with the same operability as the controller AW-RP50.
  6. The lens of PTZ cameras can be controlled with the same operability as the controller AW-RP50. In addition, the setting status (auto/manual) can be held.
  7. Latest Skype TX can be connected with AV-HLC100.
  8. Supports RTMPS streaming format required for some services such as Facebook Live.
  9. The audio mixer and switcher functions can be operated remotely from a PC/tablet device on the same network.

Version 6-5-180718

The following problems are fixed.

  1. The audio level is lower by 20 dB during the recording or playback of a clip.
  2. The clips (.mp4) cannot be played back in the Media Player.
  3. When HDMI input format is changed, the video may be distorted.
  4. REC/Stream button operations do not match GUI REC/Stream indications or operations.
  5. Fade To Black will not work when the format is 1080/50i.
  6. 1080/60p streaming/recording cannot be carried out when the format is 1080/59.94i.
  7. Recording cannot be carried out if LOW is selected for encoding while the setting is at 1080i or 1080p.
  8. A PTZ camera will not stop panning even if you switch over from it to another while you are panning it.
  9. The selection screen for speed control will not be displayed if a PTZ camera is connected to SDI with its IP specified.

Ver. 6-5-180523


  1. When the following conditions are met, the output video is unsteady on the screen and the application is forced to end. This has been corrected.
    • IP output (1080/59.94p, 1080/50p) from NDI|HX compatible equipment is input into AV-HLC100.
    • The system video format is set to 1080/59.94i or 1080/50i.
    • The output streaming is performed.
  2. The Audio Delay function can be used according to the original requirements of design.

Download the latest Firmware and Software
