Panasonic AG-UX90 | UX Series 25P UltraHD camcorder



UX Series 25P UltraHD camcorder

Product Code:

Product Discontinued

  • UX Series - Standard Model
  • Effective 1.0-type MOS Sensor
  • Opt.15x Zoom w / OIS
  • 4K (4096 x 2160) in 24p
  • UHD (3840 x 2160) up to 30p
  • Records onto SD Memory Cards
  • HDMI 2.0 output
  • Variable Frame Rate recording functionality (2-60 fps) is planned in Full HD mode.

The AG-UX90 is the “UX-series standard model” for easy, high-quality 4K/FHD recording. It is equipped with a newly designed compact lens featuring a wide 24.5mm angle*1 and 15x optical zoom. Its Optical Image Stabilizer (O.I.S.), intelligent AF function, and Manual Three Rings are ideal for professional camera work.

The AG-UX90 is equipped with a 1.0-type high-sensitivity MOS sensor. It supports UHD 25p and FHD 50p/25p multi-format recording. In addition to 4K (UHD) high resolution, it provides high-quality FHD recording at 50 Mbps. Two SD memory card slots enable relay/simultaneous recording.

The AG-UX90 also has a design and operating ease that will feel familiar to professional photographers, and a variety of interfaces, including HDMI output and XLR input. Offering the same level of agility and mobility as a conventional HD handheld camcorder, the AG-UX90 provides powerful support for high image-quality 4K/HD video production.

Newly Developed Wide-Angle 24.5mm*1 and 15x Optical Zoom LEICA DICOMAR Lens

  • 15x Optical Zoom
    The 4-Drive Lens System achieves both high image quality/sensitivity and compactness with a wide-angle 24.5mm*1 and 15x optical zoom lens. This speedy zoom provides quick zooming in and out.
  • High-Resolution Intelligent Zoom
    In FHD mode, the i.Zoom function increases the zooming capability to a maximum of 25x while maintaining high resolution. The i.Zoom function seamlessly switches on when the optical zoom limit isreached.
  • Digital Zoom (x2/x5/x10)
    The Digital Zoom function activates without any drop in light intensity. Combining the optical zoom and i.Zoom enables maximum zooming of 250x*2
    This lens has passed the stringent quality standards of Leica Camera AG. A multi-coating process minimizes ghosts and flaring, resulting in especially clear images.

*1 35mm film camera equivalent in FHD mode. 35.4mm in UHD mode.
*2 Using 15x Optical Zoom + i.Zoom + Digital Zoom 10x in FHD mode. The higher the magnification, the greater the image quality degradation.
*3 Leica is a registered trademark of Leica Microsystems IR GmbH. DICOMAR is a registered trademark of Leica Camera AG. LEICA DICOMAR products are manufactured using Leica-certified measuring instruments and quality assurance systems based on rigorous quality standards approved by Leica Camera AG.

1.0-Type MOS Sensor for High-Precision, UHD 25p or FHD 50p Recording

  • High-Image-Quality, High-Sensitivity, 1.0-Type 4K MOS Sensor
    The 1.0-type MOS sensor provides an outstanding depth of field and excellent balance between image quality and sensitivity. High-resolution recording is possible in UHD (3840x2160) 25p mode.
  • High-Image-Quality FHD Recording
    Professional, high-end image recording is possible in FHD (1920x1080) mode with a 50-Mbps bit rate.
  • UHD/FHD/SD Multi-format
    Versatile recording modes can be selected according to resolution, frame rate, bit rate, and file format.

Advanced Optical Image Stabilizer and High-Speed, High-Precision Intelligent AF

  • Advanced Optical Image Stabilizer [UHD/FHD]
    The correction area of the Optical Image Stabilizer (O.I.S.) been expanded, which provides powerful correction even in unstable shooting situations, such as low-angle or high-angle shots.
  • 5-Axis Hybrid Image Stabilizer [FHD]
    In HD shooting modes, by using hand-shake correction that combines the effects of both optical and electronic image stabilization, hand-shake in various directions, including the rotary direction, is detected and corrected.
  • Intelligent Auto Focus
    The Microdrive Focus Unit achieves superior auto focusing with higher-speed tracking and stability even in 4K images. The highest class*4 of focusing speed, tracking ability, and stability are attained in 4K video cameras.
  • Custom AF Function
    Auto focus operation can be customised by adjusting the AF Speed, AF Sensitivity and AF Area Width. This function enables the AF to operate exactly as intended by the user in accordance with the subject type or application.

*4 As a camcorder with integrated lens having a 1.0-type sensor. (As of September 2016, according to Panasonic survey.)

FHD VFR (Variable Frame Rate) Recording, Double SD Memory Card Slots

  • FHD VFR Recording
    VFR recording can be set in 9 steps from 2 to 50 fps.
  • Unlimited Relay Recording
    By using double SD memory card slots, automatically records continuously from Slot 1 to Slot 2. By changing the SD card, images can be recorded continuously for many hours*5.

*5 The maximum amount of data that can be recorded over multiple SD cards is 96 GB. Recording will not stop even when the data size exceeds 96 GB.

Camera Image Adjustment Functions, Including Details and Gamma Modes

  • Skin Detail
    Makes skin colours appear soft and beautiful. Especially effective when recording the person up close.
  • 8-Mode Gamma
    The AG-UX90 is equipped with eight selectable gamma modes, including two Cine-Like Gammas, drawing on technologies developed for the VariCam.
  • Scene Files
    Six files preset with picture quality settings are provided as Scene Files (Standard, Shooting under fluorescent lights, Spark, Still like, CINE-LIKE contrast, and CINE-LIKE dynamic range). You can change any of the settings as desired and store one set as a Custom File in the AG-UX90, and up to eight sets on an SD memory card.

Functions and Designs to Support Professional Camera Work

  • Touch-panel LCD and EVF
  • HDMI
    Digital outputs up to UHD 25p and FHD 50p.
    Outputs analogue signals for video and audio monitoring
    Equipped with two channels of XLR audio input (with switchable 48 V phantom power supply, MIC and LINE), manual audio volume and OSD level meter.
  • iPad Remote Control
    The AG ROP app for iPad*6 is available free of charge from the Apple App Store. It enables wireless remote control of the AG-UX90 with installation of a wireless module (optional AJ-WM50 or AJ-WM30). This enables a variety of control operations, including Zoom, Iris, REC Start/Stop, and picture quality settings.

*6 iOS 7.1, iOS 8.1, and iOS 9 are supported. App Store is a service mark of Apple Inc. Apple, the Apple logo, and iPad are trademarks of Apple Inc., registered in the U.S. and other countries.

Bags and Cases

Orca Bags OR-25
Orca Bags OR-25

Backpack with Large External Pockets

Orca Bags OR-26
Orca Bags OR-26

Trolley Backpack

Orca Bags OR-5
Orca Bags OR-5

Video Camera Shoulder Bag

Orca Bags OR-508
Orca Bags OR-508

Classic Video Bag for Small Video Cameras

Batteries and Power Supplies

Hedbox RP-VBD78
Hedbox RP-VBD78

57Wh 7800mAh DV Battery Pack for Panasonic - Li-Ion 7.4V (VBR)

Memory Cards

Panasonic AJ-P2M064AG
Panasonic AJ-P2M064AG

64GB MicroP2 Memory Card

New launches at ISE 2020

Here's an overview of our vendors exhibiting at ISE 2020. Please call us on +44 (0)1457 851000 if you would like to book a stand tour with one of our manufacturers. BLACKMAGIC DESIGN HALL 3, STAND C140 The Video Assist 12G 5” and 7” monitor recorders are now shipping. The original HD versions were incredibly popular with AV technicians who wanted to verify SDI and HDMI feeds and check waveform levels. For production teams, their 4K HDR capture makes them a superb on-camera SD card recorder. The ATEM Mini is a very small, cost-effective 4 channel HDMI video switcher with streaming output. Great as a portable mixer or a signal switcher, it’s being adopted by everyone from conference producers to AV technicians looking for simple HDMI switching.

Ver. 1.08


  1. On rare occasions, the operation of REC button on the unit or a wired remote control may no longer have any effect. This problem is fixed.
  2. If the card is ejected from the main slot during the simultaneous recording, the recording in the sub-slot stops 10 hours after the start of recording. The indication shows the same as during recording, and the operations of REC button are refused. This problem is fixed.
  3. LCD may not show anything when the camera is booted up. This problem is fixed.
  4. A very few SD cards may have a write error. This problem is fixed.
  5. If the network address is changed when WIRELESS SETUP is set to [DIRECT] and DHCP is set to [SERVER], it sometimes made the camera impossible to connect to the iPad. This problem is fixed.

Ver. 1.07

  1. After a test tone is output, if you switch to camera mode and start recording, on rare occasions periodic noise is recorded. This problem is fixed.
  2. If the recording is not completed correctly due to a power interruption or others, the clip will be repaired automatically by rebooting the camera.
    But, if the card is in the different slot from the one used in this incomplete recording and the auto-repair process is started, the damaged clip (MOV/MP4 file) will be deleted.
    This will not occur on files except MOV/MP4 mode. This problem is fixed.

Ver. 1.03

If you start recording at the settings that meet the following conditions, it becomes impossible to operate the camera. The problem with the firmware is corrected.

  1. PreREC is “ON”. (Default: OFF)
  2. SIMUL_REC is “ON”. (Default: OFF)
  3. Recording mode is “AVCHD”. (Default: MP4)

Download the latest Firmware and Software

  • 1 x AG-UX90
  • 1 x Battery Pack
  • 1 x Battery Charger
  • 1 x AC Adapter
  • 1 x AC Cable
  • 1 x Microphone Holder
  • 2 x 12mm Microphone Holder Mounting Screws
  • 1 x Eye Cup
  • 2 x INPUT Terminal Caps
  • 1 x Lens Hood
