Magewell Ultra Encode HDMI | Flexible & Affordable Universal Encoder

• Flexible & Affordable Universal Encoder
• Live H.264/H.265 streaming
• Supports streaming protocols including SRT, NDI®|HX, HLS & more
• Suitable for various network environment

Input Features

• Support for up to 4096x2160 4:4:4/4:2:2 30fps or 4096x2160 4:2:0 60fps input and loop through signals
• Support for 48KHz, 16-bit 8-channel audio streams
• Input audio from 3.5 mm LINE IN

Encoding Features

• Dual stream encoding profiles: main stream and sub stream (Max bitrate: 16Mbps)
• Support for H.264/HEVC video encoding
• Encoding 2-channel AAC at 48kHz, 16-bit

Streaming Features

• Natively support streaming to Facebook, Twitch and YouTube
• Supported streaming protocols: RTSP/RTMP/RTMPS/SRT Caller/SRT Listener/NDI|HX2/HLS/TS over UDP/TS over RTP
• Allow streaming to multiple destinations simultaneously (select protocols)

Others

• Internet connectivity via wired Ethernet and wireless network
• Remote control via Web GUI and Control Hub
• Provide HTTP APIs
