Video Monitors

Datavideo TLM-102 | Dual 10" Monitor

Datavideo
Datavideo Solutions

TLM-102

Dual 10" Monitor

Product Code: DATATLM102

Suggested Retail Price £1222+VAT

Where to buy Videos

Have a question about this product or want to request a demo?

Contact Our Technical Team

Kit List

View your Kit List
  • Dual 10” Monitor with 1280*800 IPS Panel Resolution.
  • Dual Monitor with 4RU Rack Mount.
  • Support 3G-SDI video input with loop-through output.
  • Support HDMI video input with loop-through output.
  • Support OSD menu for various functions including Column (YRGB peak), time code, waveform, vector scope, audio level meter, peaking, zoom, pix to pix, underscan, check field, etc.
  • Support SDI & HDMI Cross Conversion.
  • Individual adjustment of Brightness, Contrast, Color Saturation and LED Backlight Level for each monitor.
  • Colour temperature menu option has 4 modes ( 6500K, 7500K,9300K and user defined)
  • Support front panel headphone jack.
  • Support 15 pin Tally input interface.
  • Support User-definable function buttons F1 and F2

Specifications

  • Screen: 10.1" LCD
  • Chassis: 4RU Rack Mount
  • Resolution: 1280 x 800
  • Viewing Angle: (H) 170° | (V) 170°
  • Luminance/Contrast: 300 cd/m² | 800:1
  • Video Inputs: 1x 3G/HD/SD-SDI | 1x HDMI
  • Loop Through: 1x 3G/HD/SD-SDI | 1x HDMI
  • Supported Input Resolutions: 1080p (23.98/24/25/29.97/30/50/59.94/60Hz), 1080i (50/59.94/60Hz), 720p (23.98/24/25/29.97/30/50/59.94/60Hz), 480i (NTSC), 576i (PAL)
  • Aspect Ratio: 16:9, 4:3
  • Tally LED: Live (Red) | Cued (Green)
  • Audio In/Out: Embedded Audio on SDI and HDMI | Headphone Jack
  • Special Features: Time Code, Waveform, Vector Scope & Audio Level Meter, Peaking, Zoom, Pix to Pix, Underscan, SDI, HDMI Cross Conversion
  • Power: DC 12V, 26 watts

The Datavideo TLM-102 Dual 10” monitor is a 4RU Rack mount dual monitor which is designed for the broadcast quality monitoring application. Datavideo TLM-102’s 4RU rack design, SDI and HDMI inputs and outputs and different mounting methods make it the best solution for various applications such as live vans, on-site monitoring and video wall.  The TLM-102 brings high quality and user friendly viewing experience for users via its excellent display quality and advanced auxiliary functions.

New launches at ISE 2020

Here's an overview of our vendors exhibiting at ISE 2020. Please call us on +44 (0)1457 851000 if you would like to book a stand tour with one of our manufacturers. BLACKMAGIC DESIGN HALL 3, STAND C140 The Video Assist 12G 5” and 7” monitor recorders are now shipping. The original HD versions were incredibly popular with AV technicians who wanted to verify SDI and HDMI feeds and check waveform levels. For production teams, their 4K HDR capture makes them a superb on-camera SD card recorder. The ATEM Mini is a very small, cost-effective 4 channel HDMI video switcher with streaming output. Great as a portable mixer or a signal switcher, it’s being adopted by everyone from conference producers to AV technicians looking for simple HDMI switching.

The perfect breakout assistant

Datavideo's DAC-75T is designed to convert video signals from VGA, HDMI, SDI to HDMI or SDI. With touchscreen control, it's a great ally for venues, conference teams and AV rental teams that need to be ready for whatever the presenter needs to project.  DAC-75T makes childplay of connecting your source to a screen or projector. The DAC-75T does upscaling, downscaling and standards conversion for any HDMI, VGA or SDI device to any HDMI or SDI screen or projector. RCA inputs allow audio to be embedded to the output of the video signal for recording purposes.

Terms that just won’t go away!

We have moved on since the 80s and 90s and left terms such as Betamax and S-Video languishing in museums (http://www.obsoletemedia.org/). Underscan and Overscan still crop up, however, in monitor specs. These terms have their roots in old analogue television, when using CRTs or Cathode Ray Tube monitors and TV sets. Due to the way the electron gun worked inside the old TV tube part of the outside edge of the image was intentionally cropped as it was not the same image quality.

  • 1 x TLM-102
  • 1 x DC 12V Power adapter
  • 1 x Tally Connector
  • 1 x Manual
IBC 2017 - Datavideo TLM-102
IBC 2017 - Datavideo TLM-102
