SE-3200

12-Channel HD Digital Video Switcher

Product Code: DATASE3200

Suggested Retail Price £5057+VAT

Where to buy Videos

Have a question about this product or want to request a demo?

Contact Our Technical Team

Kit List

View your Kit List

Technology Guides

  • 12 Video Input Channels: 8 x SDI and 4 x HDMI
  • 9 Video Output Channels: 6 x SDI and 3 x HDMI
  • 4 Upstream Keys for chromakey, linear and luma keys as well as picture-in-picture
  • 8 Picture-in-Picture (4 flex source included), with configurable ratio, position and size
  • 2 Downstream Keyers for linear and luma keys
  • 2 static or animated logos with configurable position and size
  • WIPE, MIX, DVE and CUT transitions
  • 32 WIPE patterns such as circle and heart with adjustable border width and color softness
  • Supports stinger transition for live sports broadcast
  • Any input (1-12) can be used as a frame store
  • Supports XPT (Cross Point Assignment)
  • 4 XLR analogue audio input channels with each channel carrying four audio tracks
  • 2 XLR de-embedded analogue audio output channels
  • Dual color (red/green) tally outputs
  • Supports Tri-Level and Black Burst sync reference
  • 2 readily available user memory presets

Specifications

  • Video Standard: HD
  • Video Format: 1080p 50/59.94/60Hz | 1080i 50/59.94/60Hz | 720p 50/59.94/60Hz | 576i 50Hz | 480i 59.94Hz
  • Video Processing: SDI: 4:2:2 | HDMI: YUV 4:2:2, RGB: 4:4:4
  • Input Routable / Crosspoint: All 12, repeatable
  • Video Input: 8x SDI, 4x HDMI
  • Mix HD & SD source: Selectable HD or SD
  • Computer Graphic Interface: 4 via HDMI
  • Video output: 6x SDI Outputs assignable: AUX 1-4, PGM, PVW, PGM Clean & multi-view | 3x HDMI assignable: PGM & multi-view
  • Down-converted output: N/A
  • Built-in Multi-view monitoring out: HDMI
  • Audio input: 4x Balanced XLR
  • Audio output: 2x Balanced XLR
  • Embedded audio support: embedded 4-CH audio output
  • Audio Delay Calibration: up to 16 fields or 8 frames per channel
  • A+V switching: Yes
  • Chromakey: 4
  • Title Creator: Yes
  • USK: 4x USK support Chromakey & Linear/ Luma Key
  • DSK: 2x DSK support Lumakey & Linear key (Key / Fill)
  • Picture in Picture: 4
  • Logo Insertion: 2
  • Still Store: 500+
  • Effects: DVE, FTB, Cut, 32 Wipe with border
  • Transition Preview: Full transitions preview
  • Sync / Reference In/Out: Built-in Genlock, Support external sync with loop thru
  • Tally Output: 1x D-sub 25pin, dual color
  • PC Remote Control: Via Ethernet (free Window software) or RS-422 / RS-232
  • Built-in Audio Mixer: N/A
  • Special Features: 4 User Memory Preset | Stinger transition
  • Chassis: 2 units, 2RU rack-mount mainframe
  • Power: DC 12V

The SE-3200 is a professional 12-channel, 1080p video switcher that provides powerful and easy-to-use video effects such as four upstream keyers for Chromakey and Luma Key, dual DSK, PIP, and WIPE transitions. There are also other features like frame store, animated transition effects, multi-channel inputs, and abundant visual effects. The built-in subtitle generation system can be paired with Datavideo’s CG software to instantly create broadcast quality subtitles.

The SE-3200’s modular design allows you to install the 2U main unit on a standard 19-inch rack and place the control panel on a flat work bench, or it can be installed in an outdoor broadcast van. The SE-3200 facilitates video switching, whether indoor or outdoor.

Datavideo TPC-700P
TPC-700P

7-Inch Touch Panel Controller with PoE
[DATATPC700P]

SRP: £910+VAT
Datavideo TPC-700
TPC-700

Touch Panel Controller
[DATATPC700]

SRP: £808+VAT
Datavideo CB-68
CB-68

70m 2-in-1 Cable (4.5C HD-SDI/CAT 6)
[DATACB68]

SRP: £757+VAT
New launches at ISE 2020

Here's an overview of our vendors exhibiting at ISE 2020. Please call us on +44 (0)1457 851000 if you would like to book a stand tour with one of our manufacturers. BLACKMAGIC DESIGN HALL 3, STAND C140 The Video Assist 12G 5” and 7” monitor recorders are now shipping. The original HD versions were incredibly popular with AV technicians who wanted to verify SDI and HDMI feeds and check waveform levels. For production teams, their 4K HDR capture makes them a superb on-camera SD card recorder. The ATEM Mini is a very small, cost-effective 4 channel HDMI video switcher with streaming output. Great as a portable mixer or a signal switcher, it’s being adopted by everyone from conference producers to AV technicians looking for simple HDMI switching.

Published: 5 years ago
The perfect breakout assistant

Datavideo's DAC-75T is designed to convert video signals from VGA, HDMI, SDI to HDMI or SDI. With touchscreen control, it's a great ally for venues, conference teams and AV rental teams that need to be ready for whatever the presenter needs to project.  DAC-75T makes childplay of connecting your source to a screen or projector. The DAC-75T does upscaling, downscaling and standards conversion for any HDMI, VGA or SDI device to any HDMI or SDI screen or projector. RCA inputs allow audio to be embedded to the output of the video signal for recording purposes.

Published: 5 years ago
  • 1 x SE-3200
  • 1 x SE-3200 Control Board
  • 2 x AD Switch DC 12V
  • 1 x AC Cord
  • 1 x DB9P to DB9P Cable
  • 12 x Screws
  • 2 x 2U Ear Rack
