Product Code: BMD-CINECAMURSAM46K/EF
Compact digital film camera with high performance 4.6K HDR sensor for shooting up to 300 fps
Warranty information available from Blackmagic Design's website
The compact URSA Mini camera with EF lens mount, 4.6K Super 35 sensor and an incredible 15 stops of dynamic range, is lightweight and perfectly balanced for handheld use and comfortable enough for all day shooting. URSA Mini 4.6K EF features professional 12G-SDI connections, 5” fold out touchscreen monitor and side grip with camera control functions as well as dual CFast card recorders, built in stereo microphones and more.
Blackmagic URSA Mini is designed to be used on feature films, television shows, commercials, indies, documentaries, music videos and more. The stunning quality of its 4.6K sensor with 15 stops of dynamic range lets you capture epic cinematic shots, while its compact size is perfect for solo shoots or smaller crews! You can easily customize URSA Mini with high quality cinema lenses, rails, matte boxes and more. The optional shoulder mount kit features a quick release mounting plate so you can go from handheld to shoulder or tripod in seconds, making it perfect for pickup and run shooting situations. It’s the handheld Super 35mm digital film camera that you can use anywhere and, because it’s an URSA, everything you need is built right in.
URSA Mini features a compact, perfectly balanced body made out of advanced technology magnesium alloys so it’s rugged, lightweight and comfortable enough to be used all day. Like all URSA cameras, it includes everything you need built right in! You get a super bright 5 inch fold out 1080 HD touch screen for on-set monitoring and to change camera settings, professional connectors such as 12G-SDI, a high quality stereo microphones and a side grip with control buttons mounted on a standard rosette. The optional Blackmagic viewfinder and shoulder mount kit allow you to go from tripod to over the shoulder shooting in seconds, so you can keep up with the action.
Blackmagic URSA Mini is completely customizable so you can create a rig that’s built specifically for your production! You can add accessories like the Blackmagic URSA Viewfinder and Blackmagic URSA Mini Shoulder Kit, or choose from hundreds of third party accessories. URSA Mini has 9 standard ¼” threaded mounting points on the top and bottom of the camera so you can mount it directly to a tripod as well as add accessories such as rails, sliders, matte boxes, microphones, ring lights, batteries and more. Whether you’re building a feature film rig or outfitting the camera for an ENG style shoot, URSA Mini has all of the mount points and connections you need.
URSA Mini operates at a resolution and dynamic range that goes well beyond traditional motion picture film. You get a 4.6K image sensor that captures up to 4608 x 2592 pixels, that’s bigger than full DCI 4K! The sensor features global shutter up to 30 frames per second and rolling shutter up to 60 frames per second with 15 stops of dynamic range. Built in refrigeration cooling ensures maximum dynamic range so you get incredibly clean pictures with amazing detail in both the dark shadows and bright highlight areas of the image. You can also choose a lower cost 4K model of URSA Mini with 12 stops of dynamic range when you don’t need the performance and are on a tighter budget.
URSA Mini can shoot at high frame rates and then play it back at the edit frame rate so you get smooth slow motion video. Simply set the sensor frame rate to get different types of slow motion effects. URSA Mini can capture full resolution 4.6K recordings at up to 60 frames per second and up to 120 frames per second in regular 1080 HD! When you need even more dramatic, higher frame rate slow motion shooting, you can use the regular URSA which can record high resolution 4.6K images at an amazing 100 frames per second.
Because URSA Mini features a 4.6K native resolution image sensor it can capture much higher resolution than Ultra HD. This means when you’re working in Ultra HD you have a lot of extra resolution that can be used through the de-bayering image processing so you can recover full colour for incredible images. The wide dynamic range blows away high end broadcast cameras to give you dramatically better images that can be colour corrected for a truly cinematic look. For faster post production, quickly switch settings to use regular video dynamic range, so you can shoot great looking video without the need for colour correction.
Blackmagic URSA Mini features dual CFast 2.0 recorders so you never have to stop recording when you need to change the media! When the current card is full, recording continues onto the second card so you can swap out the full card and just keep shooting. URSA Mini uses the latest, incredibly fast CFast 2.0 technology for recording speeds up to 350 MB/s. You get perfect high frame rate RAW recording and instant play back on the built in 5 inch screen. Files can be saved as lossless 12-bit CinemaDNG RAW for the highest possible quality, or as ProRes for easy post production workflows with minimum storage requirements.
URSA Mini comes in four models so you can choose from two different sensors and two different lens mounts. You can choose the 4.6K sensor with 15 stops of dynamic range in EF or PL lens mount models. If you’re on a tight budget, you can choose the more affordable 4K sensor with 12 stops of dynamic range with either EF or PL lens mount models. The PL mount works with professional cinema lenses and the EF models let you choose from an incredible selection of high quality photographic lenses from manufacturers like Zeiss, Canon, Sigma and more. Because EF lenses are used on high resolution DSLR cameras they have incredibly precise optics that can handle the high resolution of the URSA Mini 4.6K sensor.
The optional Blackmagic URSA Viewfinder has been designed to be the perfect match for URSA and URSA Mini digital film cameras. The Blackmagic URSA Viewfinder has the specifications demanded by high end cinematographers. You get a high resolution 1920 x 1080 colour OLED display matched with precision glass optics, adjustable diopter and built in digital focus chart so you get perfect focus every time. To preserve OLED screen life there’s a built in sensor so the OLED only turns on when you’re looking through the viewfinder. The Blackmagic URSA Viewfinder is adjustable so it can be used on both the left or the right eye. There’s even a built in record light.
The high resolution 5 inch fold out monitor includes a touchscreen so you get easy access to the revolutionary URSA camera interface. All of your settings, controls and monitoring tools are at your fingertips. That means you don’t have to hunt through confusing menus to make changes. You can see and change all camera settings, view timecode, histograms for checking levels, audio levels and a focus peaking indicator for checking focus.
Blackmagic URSA Mini features multiple connections such as 12G-SDI out, HD-SDI monitoring out, 2 LANC inputs, balanced XLR audio with phantom power, timecode in and reference input. On the front right side of the camera the 4 pin XLR DC and HD-SDI monitoring output are located in the perfect position for connecting to an optional viewfinder or on set monitor. The 12G-SDI output handles up to 2160p60 using a single BNC cable and also switches to 6G-SDI or HD-SDI depending on the shooting format.
12G-SDI is an incredible 8 times faster than regular HD-SDI which makes it fast enough for Ultra HD video at up to 60 frames per second, all over a single regular SDI cable! The high quality BNC connections are multi rate so it can automatically switch and work with 6G-SDI, 3G-SDI, and regular HD-SDI equipment. That means URSA Mini is compatible with all of your existing HD and Ultra HD equipment so you can plug it into things like ATEM live production switchers, on-set monitors, decks and more.
URSA Mini has the highest quality built in microphones and professional audio recording built in so you don’t have to carry around extra sound equipment. Use the built in stereo microphone to record natural location sound or connect professional microphones using the two XLR wide dynamic range mic inputs. The XLR connections have 48V of switchable phantom power so you can plug in everything from shot gun to wireless clip on mics for capturing every detail of the performance. You can quickly adjust levels using the physical knobs and monitor audio using the onscreen audio meters.
The built in touchscreen makes it astonishingly simple to set up and enter metadata for tagging clips. Metadata is saved directly in the video files so you don’t have to worry about managing extra sidecar files. You can import the files directly into software like DaVinci Resolve, Final Cut Pro and Avid Media Composer then use the metadata to sort, search and find the clips you need so you can spend more time on creative editing and less time managing mountains of media.
URSA Mini includes multiple ¼” mount points on the bottom so you can attach it directly to any tripod. When you need to rapidly move URSA Mini from tripod to handheld and back multiple times on a shoot the best solution is to use the optional Blackmagic URSA Mini Shoulder Kit. This kit includes the shoulder pad with built in rosettes, rail mounts and integrated quick lock release attachment points so you can instantly latch it into the quick release plate without needing to remove the shoulder pad. The kit also includes a top handle for carrying the camera and attaching accessories.
URSA Mini includes a 4-pin XLR industry standard power connector that works with 12V to 30V external power supplies. That means it’s easy to use the camera with all of your existing power supplies and batteries! URSA Mini uses the same battery power connector and mounting points on the rear of the camera as used on URSA so you can use the same range of battery plates from a wide range of manufacturers such as IDX, Frezzi, Anton Bauer and more. You can also add the optional Blackmagic URSA VLock Battery Plate for using popular V-Mount batteries.
URSA Mini includes the full version of DaVinci Resolve Studio for Mac and Windows for editing, colour grading, media management, mastering and delivery. DaVinci Resolve can easily handle the 12‑bit log RAW images from URSA Mini so you can take advantage of URSA Mini’s amazing image quality and wide dynamic range. DaVinci Resolve features advanced, multi layer timeline editing with powerful trimming tools, along with the industry’s leading suite of creative grading tools! The combination of URSA Mini and DaVinci Resolve gives you a complete production and post-production solution.
High Resolution Viewfinder for URSA range
Shoulder Mount Kit for URSA Mini
Shock and vibration isolated professional microphone mount
Arduino expansion board or “shield” to develop custom control solutions for Blackmagic Design cameras
What CFast cards should I use with Blackmagic URSA Mini, URSA Mini Pro and URSA Broadcast cameras?
The following CFast 2.0 cards are recommended for recording 4.6K Blackmagic RAW 3:1 up to 60 fps.
The following CFast 2.0 cards are recommended for recording 4.6K Blackmagic RAW 3:1 up to 60 fps but have been discontinued by the manufacturers.
The following CFast 2.0 cards are recommended for recording 2160p ProRes 422 HQ up to 60 fps.
The following CFast 2.0 cards are recommended for recording 2160p ProRes 422 HQ up to 60 fps but have been discontinued by the manufacturers.
The following CFast 2.0 cards are recommended for recording 2160p Lossless RAW up to 30 fps.
The following CFast 2.0 cards are recommended for recording 2160p Lossless RAW up to 30 fps but have been discontinued by the manufacturers.
